ART 270 HP - PN25 Stainless Steel Orifice Plate (OP)

SketchfabSketchfab
  • Views 108
  • Comments 0
  • Rating- / 5
    Rate this product
    1/5 Rating1/5 Rating2/5 Rating2/5 Rating3/5 Rating3/5 Rating4/5 Rating4/5 Rating5/5 Rating5/5 Rating

BS1192:4

Compliant

BSB

Compliant

Object Data

1 Revision

Last Updated

20/10/2020

Available for:
  • Logo: Autodesk Revit
  • Logo: Industry Foundation Class

PN25 Stainless Steel Orifice Plate (OP)

Features

  • Wafer pattern
  • Fits between BS EN1092 flanges PN25
  • Flow characteristic confirmed to BS 7350
  • Fixed orifice with ± 5% flow measurement accuracy
  • Can be close coupled to a double regulating valve
  • Supplied with 2 extensions and test points
