ART 136 - Wafer Check Valve

by Albion Valves

Download Add to collection

Description

Cast Iron Dual Plate Wafer Check Valve. Stainless Steel Disc. EPDM Seat.

Universal flange mounting to suit BS EN1092 PN10 / PN16 and ANSI B16.1 Class 125.

16 Bar Rated.

-10°C to 120°C
-10°C to +85°C (WRAS Applications)

Object Data

1 Revision

Last Updated

16/11/2023

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Available

Accompanying literature

Object User Guide

Product Certificates

Installation Guide

Product Literature

Object metadata

_AuthorAM
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Bywww.bimstore.co
_Current Revision1
_Distributed Bywww.bimstore.co
_Object User Guidewww.bimstore.co/products/art-136-wafer-check-valve/document/object-user-guide
A161 mm
Accessibility Performancen/a
ANSI CalcNo
Assembly CodeD20
Asset TypeFixed
B117 mm
BIM Object NameAlbionValves_PipeAccessories_WaferCheckValve_ART136
BodyCast Iron EN1561 EN-GJL-250
Classification NameUniclass2015
Classification ValuePr_65_54_95_11
Code Performancen/a
ColorSilver & Blue
Connection Size100 mm
Constituentsn/a
Created Bysales@albionvalvesuk.com
Created On2023-08-07 T09:00:00
Default Elevation0 mm
DescriptionCast Iron Dual Plate Wafer Check Valve
DiscStainless Steel CF8
Documentation Certificateswww.bimstore.co/products/art-136-wafer-check-valve/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/art-136-wafer-check-valve/document/installation-guide
Documentation Literaturewww.bimstore.co/products/art-136-wafer-check-valve/document/product-literature
Documentation Maintenancewww.bimstore.co/products/art-136-wafer-check-valve/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/art-136-wafer-check-valve/document/technical-data-sheet
DT7 mm
Duration UnitYear
DW112 mm
Expected Life0
EyeboltCarbon Steel
Features• Universal flange mounting to suit BS EN1092 PN10/PN16 and ANSI B16.1 Class 125 • Epoxy coat finish
FinishEpoxy Coat Finish
GAP12 mm
GasketEPDM
Graden/a
H64 mm
H/232 mm
Height Calc1 mm
Hinge PinStainless Steel 420
Ifc Export AsIfcValve
Ifc Export TypeIfcValveTypeEnum.CHECK
KeynoteS
Kv302.4
L18 mm
L26 mm
L312 mm
ManufacturerAlbion Valves
Manufacturer NameAlbion Valves
MaterialCast Iron
Max Pressure16 bar
ModelWafer Check Valve
Model NumberDN100
Model ReferenceWafer Check Valve
NBS DescriptionCast iron check valves
NBS Noten/a
NBS Object NameAlbion Valves - Cast iron check valves
NBS Office Master Tagn/a
NBS Reference90-10-90/348
Nominal Depth64 mm
Nominal Height161 mm
Nominal Length161 mm
Pin RetainerStainless Steel 304
PN16 CalcNo
Production Year2023
R12 mm
R23 mm
Referenced StandardBS EN1092, ANSI B16.1
Replacement Costn/a
SD43 mm
SeatEPDM
Shapen/a
SizeDN100
Size DN100
Spare Partsn/a
SpringStainless Steel 304
Stop PinStainless Steel 420
Thread Inch4
Thread Millimetre102 mm
Type CommentsDN100
Type NameWafer Check Valve
URLwww.albionvalvesuk.com/
Valve FinishIron, Cast, Blue
Valve Finish 2Stainless Steel AISI 304
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts5
Warranty Duration UnitYear
Warranty Guarantor Laborn/a
Warranty Guarantor Partssales@albionvalvesuk.com
WasherPTFE
Weight4.5kg
Width Calc0 mm
Working Temperature-10°C to +120°C
WRAS Applications-10°C to +85°C
