Y222P - Y-Pattern Strainer

by Watts Water Technologies EMEA B.V.

Download Add to collection

Description

The Y pattern strainer Y222P are available with a brass drain cock 1/4” (1/8” for DN 1/2) allowing a quick and efficient cleaning.

Filtration DN : 500 microns (except DN 1/2: 300 microns)

Object Data

1 Revision

Last Updated

02/12/2021

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Certificates

Installation Guide

Technical Data Sheet

Product Data Sheet

Object metadata

_AuthorAM
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/y222p-y-pattern-strainer/document/object-user-guide
A84.00 mm
a37.70 mm
Accessibility Performancen/a
Assembly CodeD2040100
Asset TypeFixed
b7.80 mm
B64.80 mm
BIM Object NameWATTS_Valve_Y-PatternStrainer_Y222P
c13.00 mm
C64.00 mm
Classification NameUniclass2015
Classification ValuePr_65_57_96_99
Code Performancen/a
ColorBrass
Connection TypeFemale/Female (BSP)
Constituentsn/a
Created Bycontact@wattswater.com
Created On2021-10-12 T09:00:00
d6.50 mm
D27.00 mm
DescriptionY222P Strainer with drain cock for backflow preventer DN15, F/F,body in brass, strainer stainless steel, PN25 , Filtration 500µ
DN15.00 mm
Documentation Certificateswww.bimstore.co/products/y222p-y-pattern-strainer/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/y222p-y-pattern-strainer/document/installation-guide
Documentation Literaturewww.bimstore.co/products/y222p-y-pattern-strainer/document/product-literature
Documentation Maintenancewww.bimstore.co/products/y222p-y-pattern-strainer/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/y222p-y-pattern-strainer/document/technical-data-sheet
Drain Cock 1Yes
Drain Cock 2No
Duration UnitYear
e14.00 mm
E123.00 mm
E223.00 mm
EAN Code3660770447657
ETIM ClassEC010151
Expected Life0
f7.50 mm
FeaturesFiltration: 300 microns
FinishBrass
g3.00 mm
Graden/a
Hex Width13.80 mm
Ifc Export AsIfcValve
Ifc Export TypeIfcFilterTypeEnum.STRAINER
KeynoteS12
ManufacturerSOCLA
Manufacturer NameSOCLA
MaterialBody - Brass, Strainer - Stainless steel
ModelY222P Y-pattern strainer
Model Number149B5950
Model ReferenceY222P Y-pattern strainer
NBS DescriptionY-type water strainers
NBS Object NameWATTS - Y-type water strainers
NBS Office Master Tagn/a
NBS Reference90-10-60/400
Nominal Depth27.00 mm
Nominal Height80.00 mm
Nominal Length84.00 mm
Operating Temperature-10°C to 110°C
PFA Water25
Production Year2021
Reference149B5950
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Size62.5 mm(L) x 49 mm(H) x 26 mm(D)
Spare Partsn/a
Strainer Length52.80 mm
Strainer Offset12.40 mm
Symbol Size10.00 mm
Thread Inch1/2
Type CommentsY222P Y-pattern strainer DN15
Type NameY222P Y-pattern strainer DN15
URLsocla.com/
Warranty Descriptionn/a
Warranty Duration Laborcontact@wattswater.com
Warranty Duration Parts0
Warranty Duration UnitYear
Warranty Guarantor Laborn/a
Warranty Guarantor Partscontact@wattswater.com
Weight0.18 kg

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
