OB36+ External Door

by Origin Doors & Windows

Download Add to collection

Description

Our OB36+ External Door epitomises the pinnacle of luxury and style. Available in a modern aesthetic as well as the sought after steel-look, it seamlessly merges cutting-edge design and ultra-slim sightlines with unparalleled functionality.

Featuring industry-leading thermal efficiency with U-Values as low as 0.78, OB36+ delivers in both style and performance for the long-term.

The following configurations are available for download:

1+0
1+1
3+0
3+1
4+0

Object Data

1 Revision

Last Updated

13/08/2025

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Data Sheet

Object metadata

_AuthorHarmandip Toor
_Authorized ByOrigin R&D
_Bim Spec Guid0
_Created Bywww.origin-globaLcom
_Current Revision1
_Distributed Bywww.origin-globaLcom
_Object User Guideorigin.turtl.co/story/external-door-installation-guide/page/1
Accessibility Performancen/a
Analytic Construction<None>
Assembly CodeB2030110
Asset TypeFixed
BIM Object NameOriginGlobal_Doors_BiFold_OB36+_(1+0)_OpenOut
Classification NameUniclass2015
Classification ValuePr_30_59_24_81
Code PerformancePAS 24:2022 Certified / BS 6375 Parts 1, 2 & 3
ColorAvailable in over 150 RAL colours
Constituentsn/a
Created Byenquiry@origin-global.com
Created On2025-08-08T09:00:00
Define Thermal Properties bySchematic Type
Depth82 mm
DescriptionOpen up your living space, garden and patio area with stunning Origin aluminium bi-folding doors, expertly made in the UK to your specification.
Documentation Certificatestrade.origin-global.com/products
Documentation Installation Guideorigin.turtl.co/story/external-door-installation-guide/page/1
Documentation Literaturetrade.origin-global.com/products
Documentation Maintenancetrade.origin-global.com/products
Documentation Technicalorigin.turtl.co/story/external-door-installation-guide/page/1
Door Leaf Offset0 mm
Duration UnitYears
Expected Life0
Export Type to IFC AsIfcDoor
FeaturesThermally broken
FinishHigh grade powder coating
Frame Width34 mm
FunctionExterior
Gap12 mm
GradeHigh grade Aluminium
Head Tolerance0 mm
Height2100 mm
Ifc Export AsIfcDoor
Ifc Export TypeIfcDoorTypeEnum.DOOR
Internal Reveal Thickness25 mm
Jamb Tolerance0 mm
KeynoteL20/530
Leaf Offset62 mm
ManufacturerOrigin Global
Manufacturer NameOrigin Global
MaterialAluminium
ModelOB-36
Model NumberOB36+
Model ReferenceBiFold Doors - 1 Panel (1+0) OpenOut
NBS DescriptionSliding folding doorsets
NBS Object NameOrigin Global - Sliding folding shutter doorsets
Nominal Depth82 mm
Nominal Height2100 mm
Nominal Length1000 mm
Number Of Door Panels1
Open InNo
Open OutYes
Production Year2025
Referenced StandardPAS 24:2022 Certified / BS 6375 Parts 1, 2 & 3
Replacement Costn/a
Rough Height2100 mm
Rough Width1000 mm
ShapeRectangle
Show HandlesYes
Size2000mm (w) x 2100mm (h)
Spare Partsn/a
Structural Opening Area2.10 m²
Thickness82 mm
Type CommentsBiFold Doors - 3 Panels (3+0) OpenOut
Type IFC Predefined TypeIfcDoorTypeEnum.DOOR
Type NameBiFold Doors - 1 Panel (1+0) OpenOut
URLorigin-global.com/
Wall ClosureBy host
Warranty DescriptionUp to a 20-year guarantee (Guarantee based on location of where the doors will be installed. Full terms and conditions can be found on the Origin website - origin-global.com/terms-and-conditions).
Warranty Duration Laborn/a
Warranty Duration Parts20
Warranty Duration UnitYears
Warranty Guarantor Laborenquiry@origin-global.com
Warranty Guarantor Partsenquiry@origin-global.com
Width1000 mm
