Fig. 971 - Fully-Lugged Lever Operated Butterfly Valve - Ductile Iron

  • ISO
  • ISO RANGE
SketchfabSketchfab
  • Views 10.8k
  • Comments 0
  • Rating- / 5
    Rate this product
    1/5 Rating1/5 Rating2/5 Rating2/5 Rating3/5 Rating3/5 Rating4/5 Rating4/5 Rating5/5 Rating5/5 Rating

BS1192:4

Compliant

BSB

Compliant

Object Data

1 Revision

Last Updated

12/08/2021

Available for:
  • Logo: Autodesk Revit

Fully-Lugged Lever Operated Butterfly Valve - Ductile Iron

Fig. 971



Features & Benefits

  • Ductile Iron Body. Aluminum Bronze Disc.
  • Liner bonded to steel backing ring.
  • High strength, low friction bearings for upper and lower shafts, to restrain shaft deflection and ensure effective stem sealing.



Pressure Rating

PN16

Product Material

Ductile Iron

Operating Pressure

PN16

Test Pressure

Shell: 24 bar
Seat: 17.6 bar
