DescriptionCrane cast iron globe valves are highly efficient for throttling because seat and disc designs provide flow characteristics with proportionate relationships between valve lift and flow rate.
Model ReferenceF372 - Cast Iron Globe Valve - Class125
NBS DescriptionCast iron globe valves
NBS Object NameCraneFS - Cast iron globe valves
NBS Office Master Tagn/a
Nominal Depth203.00 mm
Nominal Height445.00 mm
Nominal Length216.00 mm
Pressure RatingClass 125
Specification NotesValves are manufactured in accordance with BS 5152: 1974 and also meet the requirements of MSS.SP-85: 2002. End flanges conform to BS 1560 Section 3.2/ANSI B16.1 Class 125 with Flat Face and are normally supplied drilled. Valves detailed on this page are dimensioned in metric terms. This valve is not suitable for use on Group 1 gases or unstable fluids, as defined by the Pressure Equipment Directive 2014/68/EU.
StemBrass BS EN 12164 CW721R
Temperature Operating Range-10 to 230°C
Type CommentsF372 - Cast Iron Globe Valve - Class125
