DM950G - Flow Measurement and Regulating Valve

by Crane Fluid Systems

Download Add to collection

Description

DM950G- DN50 to DN400

Flow Measurement and Regulating Valve

Features & Benefits

The DM950G and DM950L consist of a DM925G/L coupled with a fixed orifice flow measurement device using a spool piece connector, to form a fixed orifice flow measurement unit with regulation and isolation capability
The DM950G and DM950L is supplied ready assembled to site
Test points are supplied loose
Suitable gasket and bolting should be provided by the contractor/installer

Size	DN50 to DN400
Pressure Rating	PN16
Temperature Rating	10 - 120°C

Object Data

1 Revision

Last Updated

13/09/2022

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Installation Guide

Technical Data Sheet

Object metadata

_AuthorAM
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/crane-fs-dm950g/document/object-user-guide
Accessibility Performancen/a
Angle22.50 °
Assembly CodeD2090800
Asset TypeFixed
BIM Object NameCraneFS_BalancingValve_FlowMeasurementRegulatingValve_DM950G
Classification NameUniclass 2015
Classification ValuePr_65_54_95_27
Code Performancen/a
ColorBlack
Connection Radius50.00 mm
Connection Size100.00 mm
Constituentsn/a
Created Byenquiries@cranefs.com
Created On2022-08-01T:09:00:00
DescriptionDM950G - Flow Measurement and Regulating Valve
Documentation Certificateswww.bimstore.co/products/crane-fs-dm950g/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/crane-fs-dm950g/document/installation-guide
Documentation Literaturewww.bimstore.co/products/crane-fs-dm950g/document/product-literature
Documentation Maintenancewww.bimstore.co/products/crane-fs-dm950g/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/crane-fs-dm950g/document/technical-data-sheet
Duration UnitYear
Expected Life0
Extension Piece52.95 mm
F629 Depth52.00 mm
Featuresn/a
Finishn/a
Flow303 Kv
Graden/a
Head Loss2.0 K
Ifc Export AsIfcValve
Ifc Export TypeIfcValveType.DRAWOFFCOCK
K Coefficient0
KeynoteS
Kvs220 KVS
Loss MethodK Coefficient
ManufacturerCrane FS
Manufacturer NameCrane FS
Materialn/a
ModelDM950G - Flow Measurement and Regulating Valve
Model NumberDM950G
Model ReferenceDM950G - Flow Measurement and Regulating Valve
NBS DescriptionDraining taps
NBS Noten/a
NBS Object NameCrane FS - Draining taps
NBS Office Master Tagn/a
NBS Reference90-10-90/374
Nominal Depth181.00 mm
Nominal Height385.00 mm
Nominal Length247.00 mm
Orifice Plate Depth1.60 mm
Orifice Plate Gasket Depth1.50 mm
Orifice Plate Retainer Depth20.00 mm
Overall Depth181.00 mm
Pressure RatingPN16
Production Year2022
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Size1/2" - DN15
Spare Partsn/a
Temperature Operating Range-10 to 120°C
Type CommentsDM950G - Flow Measurement and Regulating Valve
Type NameDM950G - Flow Measurement and Regulating Valve
URLwww.cranefs.com/
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYear
Warranty Guarantor Laborenquiries@cranefs.com
Warranty Guarantor Partsenquiries@cranefs.com
Weight27.00 kg
Wheel Dia150.00 mm
Wheel Height202.00 mm

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
