Billi Quadra with XT Touch Dispenser

by Billi

Download Add to collection

Description

The Quadra Boiling and Chilled drinking water system is a high capacity, commercial drinking water solution that maintains the core Billi design principles and requires no joinery ventilation. The drawcard for the entire Quadra range is the use of innovative energy reclaim technology which enables space savings, energy efficiency and completely eliminates exhaust heat transfer. All Quadra boiling and chilled products are Global Greentag certified to a Gold standard.

The XT touch dispenser is an innovative, contemporary design, which has a touch sensitive panel offering a sophisticated and clean style.

Dispenser design	XT Touch
Capacity	Up to 40 - 100 Persons
Underbench Size	Compact = 340mm h x 315mm w x 365mm d \| 440, 460, 4100 = 340mm h x 315mm w x 465mm d
Product Code	Compact = 904010T \| 440 = 904040T \| 460 = 904060T \| 4100 = 904100T
Water Combination	Boiling \| Chilled

Object Data

1 Revision

Last Updated

15/08/2025

Available Software

BSB

Compliant

EPD

Not Available

_AuthorIH
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Bymarketing@billi-uk.com
_Current Revision0
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/
Accessibility Performancen/a
Assembly CodeD2020
Asset TypeFixed
BIM Object NamePlumFixt_Assembly_BilliUK_Quadra_XT
Boiling Water Delivery250 cups per hour
CapacityUp to 100
Chilled Sparkling Water Delivery175 cups per hour
Classification NameUniclass2015
Classification ValuePr_40_70_23_42
Code Performancen/a
ColorBR - Brushed
Compact UnitPlumFixt_Billi_UnderbenchUnit_Quadra : Billi Quadra Compact
Constituentsn/a
Created Bymarketing@billi-uk.com
Created On2025-02-20T09:00:00
Cups Per Hour NoteBased on a set volume of water being drawn every 30 seconds at an inlet temperature of average temperature 21°C. Each cup is equivalent to 170ml.
CW ConnectionYes
Default Elevation0 mm
DescriptionInstant boiling and chilled filtered water system.
Dispenser DesignXT Touch Dispenser
Documentation Certificateswww.billi-uk.com/product/billi-quadra-4100-with-xt-touch-dispenser/
Documentation Installation Guidewww.billi-uk.com/wp-content/uploads/2021/10/Quadra-and-Quadra-Plus-User-Guide.2022.pdf
Documentation Literaturewww.billi-uk.com/product/billi-quadra-4100-with-xt-touch-dispenser/
Documentation Maintenancewww.billi-uk.com/product/billi-quadra-4100-with-xt-touch-dispenser/
Documentation Technicalwww.billi-uk.com/wp-content/uploads/2021/10/6913_Billi-UK_Comm-Datasheets-Quadra-4100-XT_FA.pdf
Duration UnitYears
Expected Life0
FeaturesEnergy efficient. Adjustable chilled temperature. Heat exchange technology. HACCP certified. No cupboard ventilation required. BPA free.
Filter 1Filter : 5 Micron Fibron X
Filter 2Filter : 0.2 Micron Fibron XC
Filter 3Filter : HSD Fibron XT
Filter 4Filter : Sediment Only
Filter 5Filter : 0.2 Micron HF Sediment Only
Finishn/a
Font MaterialBilli_Metal_Brushed
Graden/a
HW ConnectionNo
Ifc Export AsIfcValve
Ifc Export TypeIfcValveTypeEnum.FAUCET
KeynoteN13
ManufacturerBilli
Manufacturer NameBilli
Materialn/a
ModelBilli Quadra 4100 with XT Touch Dispenser
Model Number904100TBRUK
Model ReferenceBilli Quadra 4100 with XT Touch Dispenser
NBS DescriptionInstant boiling and cold water taps
NBS Noten/a
NBS Object NameBilli - Instant boiling and cold water taps
NBS Office Master Tagn/a
NBS Reference90-15-35/485
Nominal Depth466 mm
Nominal Height340 mm
Nominal Length315 mm
Power SupplyA dedicated 20amp double pole switched spur must be fitted at a high level and accessible within the cupboard. The unit comes with a 1 metre flex cord.
Production Year2025
Referenced Standardn/a
Replacement Costn/a
Riser MaterialBilli_Metal_Brushed
Shapen/a
Sizen/a
Spare Partsn/a
Tap MaterialBilli_Metal_Brushed
Type CommentsBilli Quadra 4100 with XT Touch Dispenser Brushed (904100TBRUK)
Type NameBilli Quadra 4100 with XT Touch Dispenser Brushed (904100TBRUK)
Underbench Size340mm h x 315mm w x 465mm d
Underbench UnitPlumFixt_Billi_UnderbenchUnit_Quadra : Billi Quadra
Underbench Unit Depth466 mm
Underbench Unit Height340 mm
Underbench Unit Width315 mm
URLwww.billi-uk.com/product/billi-quadra-4100-with-xt-touch-dispenser/
Vent ConnectionNo
Warranty DescriptionAll components of the drinking water systems are covered by a 24-month warranty.
Warranty Duration Labor2
Warranty Duration Parts2
Warranty Duration UnitYears
Warranty Guarantor Laborwww.billi-uk.com/customercare/request-service-support/
Warranty Guarantor Partswww.billi-uk.com/customercare/request-service-support/
Waste ConnectionNo
Water TypeBoiling Chilled
