Whole Home Dehumidifiers (Series 4000)

by Resideo: Smart Home Products and Systems

Download Add to collection

Description

Engineered for versatility, efficiency, and long-term value, the Series 4000 delivers powerful moisture control for any home. Featuring a tri-directional outlet, it offers unmatched installation flexibility—giving contractors the adaptability they need for any space.

This ENERGY STAR® certified lineup includes the only 65 PPD small-capacity unit on the market, helping homeowners save energy without compromising performance. With replaceable components, maintenance is faster and more cost-effective - keeping homes comfortable and contractors in control.

Capacity Range: 65 PPD - 120 PPD

Models: DHM065, DHM090, DHM120

SKUs: DHM065R4000/U, DHM090R4000/U, DHM120R4000/U

Click here to learn more at Resideo!

Object Data

1 Revision

Last Updated

17/09/2025

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

_AuthorSM
_Authorized Bybimstore
_Bim Spec Guid17
_BS Bible Version0
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
120Yes
65No
90No
Accessibility Performancen/a
Airflow400 CFM @ 0" Static Pressure
Assembly CodeD3090200
Asset TypeFixed
Auxiliary Output24VAC, 40VA
BIM Object NameResideo_WholeHomeDehumidifier_DHM0120R4000
Classification NameUniclass2015
Classification ValuePr_65_67_39
Code Performancen/a
ColorGrey
Compliance StandardsETL Listed per UL 60335-1, 60335-2-40, CSA C22.2 No. 60335-1 and 60335-2-40
Constituentsn/a
Created Bywww.resideo.com/gb/en/contact-us/
Created On2025-08-21 T09:00:00
Default Elevation0 mm
DescriptionWhole Home Dehumidifier
Duhumification Capacity120 pints/day @ 80°F, 60%RH
Duration UnitYears
Energy Efficiency RatingDHM120: 2.41L/kWh (Energy Star 6.0 compliant)
Expected Life0
Featuresn/a
Filter Body Type1” MERV 8
Filter Mesh Recommended Change Period1 month
Filter Mesh Size14” x 20”
Finishn/a
Graden/a
Humidity Control Range30% to 70%
Ifc Export AsIfcEnergyConversionDeviceType
Ifc Export TypeIfcHumidifierTypeEnum.ASSISTEDSTEAM
Input Voltage120VAC @ 60 Hz
KeynoteU
Maintenance ScheduleMonthly inspection
ManufacturerResideo
Manufacturer NameResideo
Materialn/a
ModelDHM120R4000
Model NumberDHM0120R4000
Model ReferenceDehumidifier
Mounting TypeFloor / Ducted
NBS DescriptionDesiccant dehumidifiers
NBS Noten/a
NBS Object NameResideo - Desiccant dehumidifiers
NBS Office Master Tagn/a
NBS Reference90-45-55/340
Noise Level63 dB @ 3 fts distance
Nominal Current7.3 A
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Operating Ambient Temperature Range34 F to 130 F
Operating Relative Humidity0% to 95% RH, non-condensing
Operating Temperature Range-20 F to 140 F
Production Year2025
Referenced Standardn/a
Replacement Costn/a
ShapeCuboid
Shipping Weight101.5 lbs
Spare Partsn/a
Type CommentsWhole Home Dehumidifier 120 PPD for homes over 3,500 sq. ft. - DHM0120R4000
Type NameWhole Home Dehumidifier 120 PPD - DHM0120R4000
Unit Weight100.00 kg
URLwww.resideo.com/
Warranty5 years
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborwww.resideo.com/gb/en/contact-us/
Warranty Guarantor Partswww.resideo.com/gb/en/contact-us/
