OW-70 Aluminium Window - Fixed Frame

Object metadata

• _AuthorRyan Wigham
• _Authorized Bybimstore
• _Bim Spec Guid0
• _BS Bible Version16
• _Created Bywww.bimstore.co
• _Current Revision1
• _Distributed Bywww.bimstore.co
• _Object User Guidewww.bimstore.co/products/ow-70-aluminium-window-fixed-frame/document/object-user-guide
• Accessibility Performancen/a
• Assembly CodeB2020110
• Asset TypeFixed
• BIM Object NameOriginGlobal_Window_Aluminium_OW70_Fixed
• Classification NameUniclass2015
• Classification ValuePr_30_59_98_02
• Code PerformanceBS EN 1670:2007 Grade 4 / BS EN 10088-2 Grade Certified
• ColorAvailable in over 150 RAL colours
• Constituentsn/a
• Created Byenquiry@origin-global.com
• Created On2020-03-16T09:00:00
• Default Cill Height800 mm
• Depth70 mm
• DescriptionBeautiful, elegant and simplistic, the Origin Slimline Window is designed for spaces where maximising glass and light is essential.
• Documentation Certificatesorigin-global.com/
• Documentation Installation Guidewww.bimstore.co/products/ow-70-aluminium-window-fixed-frame/document/installation-guide
• Documentation Literaturewww.bimstore.co/products/ow-70-aluminium-window-fixed-frame/document/product-literature
• Documentation Maintenanceorigin-global.com/
• Documentation Technicalwww.bimstore.co/products/ow-70-aluminium-window-fixed-frame/document/technical-data-sheet
• Duration UnitYears
• Expected Life0
• FeaturesAccommodates double and triple glazing, with a 28mm glazing unit size available
• FinishAluminium
• Glass Offset_EXT33 mm
• Glass Thickness4 mm
• Glazing Thickness28 mm
• GradeHigh grade Aluminium
• Head Tolerance0 mm
• Height1000 mm
• Ifc Export AsIfcWindow
• Ifc Export TypeIfcWindowTypeEnum.WINDOW
• Internal Reveal Thickness25 mm
• Jamb Tolerance0 mm
• KeynoteL10/330
• ManufacturerOrigin Global
• Manufacturer NameOrigin Global
• MaterialHigh grade aluminium
• ModelOW-70
• Model NumberOW-70
• Model ReferenceFixed picture frame window
• NBS DescriptionAluminium window units
• NBS Noten/a
• NBS Object NameOrigin Global - Aluminium window units
• NBS Office Master Tagn/a
• NBS Reference45-25-99/310
• Nominal Depth70 mm
• Nominal Height1000 mm
• Nominal Length1000 mm
• Production Year2020
• Referenced StandardPAS 24:2016 (Document Q Compliant) and Secured by Design
• Rough Height1000 mm
• Rough Width1000 mm
• ShapeRectangle
• Size1000mm (w) x 1000mm (h)
• Spare Partsn/a
• Structural Opening Area1.00 m²
• Type CommentsFixed picture frame window
• Type NameFixed picture frame window
• URLorigin-global.com/
• Wall ClosureBy host
• Warranty DescriptionUp to a 20-year guarantee (Guarantee based on location of where the windows will be installed. Full terms and conditions can be found on the Origin website - origin-global.com/terms-and-conditions).
• Warranty Duration Laborn/a
• Warranty Duration Parts20
• Warranty Duration UnitYears
• Warranty Guarantor Laborenquiry@origin-global.com
• Warranty Guarantor Partsenquiry@origin-global.com
• Width1000 mm
