RAPID SLX 3-in-1 set for WC, 1.13 m installation height (39598000)

by GROHE

Download Add to collection

Description

Rapid SLX3-in-1 set for WC, 1.13 m installation height with flushing cistern GD 2 consisting of: Rapid SLX element for WC (39 596 000) with integrated power socket Rapid SL wall brackets (38 558 00M) WC set for noise protection (37 131 000) including flow manager.

Object Data

1 Revision

Last Updated

05/05/2020

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Product Data Sheet

Object metadata

_AuthorAM
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co
_Current Revision1
_Distributed Bywww.bimstore.co
Accessibility Performancen/a
Apparent Load0 VA
Assembly CodeD2010900
Asset TypeFixed
BIM Object NameGrohe_PlumbingFixtures_WallHungWCFrame_RapidSLX-39598000
Cistern MaterialGrohe - ABS Plastic - White
Classification NameUniclass2015
Classification ValuePr_40_20_93_89
Code Performancen/a
ColorBlue
Constituentsn/a
Created Byinfo-uk@grohe.com
Created On2020-04-07 T09:00:00
CW ConnectionYes
Depth130.00 mm
DescriptionRapid SLX3-in-1 set for WC, 1.13 m installation height with flushing cistern GD 2 consisting of: Rapid SLX element for WC (39 596 000) with integrated power socket, Rapid SL wall brackets (38 558 00M) WC set for noise protection (37 131 000) including flow manager.
Documentation Certificateswww.grohe.co.uk/
Documentation Installation Guidewww.bimstore.co/products/rapid-slx-39598000/document/installation-guide
Documentation Literaturewww.bimstore.co/products/rapid-slx-39598000/document/product-literature
Documentation Maintenancewww.grohe.co.uk/
Documentation Technicalwww.grohe.co.uk/
Duration UnitYear
Expected Life0
Featuresn/a
FinishPowder-coated steel
Frame MaterialGrohe - Powder Coated Steel - Blue
Graden/a
Height1085.00 mm
HW ConnectionNo
Ifc Export AsIfcFlowTerminalType
Ifc Export TypeIfcSanitaryTerminalTypeEnum.CISTERN
KeynoteN13
Length500.00 mm
ManufacturerGrohe
Manufacturer NameGrohe
MaterialPowder-coated steel
Model39598000
Model NumberRapid SLX 3in1 WC 6 l 1,13m with wall brackets and noise protection
Model Reference39598000
NBS DescriptionGrohe - WC cisterns
NBS Object NameWC cisterns
NBS Office Master Tagn/a
NBS Reference45-35-70/383
Nominal Depth130.00 mm
Nominal Height1085.00 mm
Nominal Length500.00 mm
Plate MaterialGrohe - Steel
Production Year2020
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Size500mm(l) x 130mm(d)
Spare Partsn/a
Type CommentsRapid SLX 3in1 WC 6 l 1,13m with wall brackets and noise protection
Type Name39598000
URLwww.grohe.co.uk/
Vent ConnectionNo
Voltage0 V
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYear
Warranty Guarantor Laborn/a
Warranty Guarantor Partsn/a
Waste ConnectionYes
