Grohe Rapid SL - 39112001

Object metadata

• _AuthorRyan Lashley
• _Authorized ByKris Atkinson
• _Bim Spec Guid0
• _BS Bible Version14
• _Created Bywww.bimstore.co.uk
• _Current Revision1
• _Distributed Bywww.bimstore.co.uk
• Accessibility Performancen/a
• ADA CompliantNo
• Assembly CodeD2010
• Asset TypeFixed
• BIM Object NamePlumbingFixture_GroheLimited_RapidSL_39112001_METRIC
• Classification NameUniclass2015
• Classification ValuePr_40_20_93_79
• Code Performancen/a
• Cold Water Connection Diameter10 mm
• ColorBlue & White
• Constituentsn/a
• Contact GroheGROHE Limited, World Business Centre 2, Newall Road, London Heathrow Airport, Hounslow, Middlesex, TW6 2SF - Tel: +44 (0) 871 200 3414 - Fax: +44 (0) 871 200 3415 - Email: info-uk@grohe.com
• Created Byinfo-uk@grohe.com
• Created On2017-05-08T00:00:00
• CW ConnectionNo
• CWFU4.5
• Default Elevation0 mm
• Descriptionflushing cistern GD 2 with connections for GROHE Sensia. shower toilets (GROHE Sensia IGS/GROHE Sensia Arena). with maintenance access. 1.13 m finished installation height. for on-the-wall installations or studded walls. powder coated steel frame, self-supporting. for dry-cladding, completely pre-assembled. with fixed connections. for single or series installation. quick adjustment, lockable. fixing material. TÜV approved. 2 WC fixing bolts. fixing device for ceramic. distance of fixing bolts 180/230 mm. PP outlet bend Ø 90 mm. depth adjustable. reducer Ø 90/110 mm. inlet and outlet connecting set. flushing cistern GD 2, 6 - 3 l. pneumatic discharge valve offering 2 modes of operation: dual flush or single flush. rear water supply. low noise (group I acc. to German Noise Specification). Insulated against condensation. ½" water supply connection including integrated. angle valve and push fit flexible hose union. no tools required for the installation. of the inspection shaft incl. protection. during construction phase. for vertical or horizontal use. 2 wall brackets with fixing material. universal water connection for shower toilets Sensia Arena and Sensia IGS. concealed socket for mains supply. positioning help for electrical connection. for mounting of small flush plates please order. revision shaft 40 911 000 (sold separately).
• Documentation Certificatesn/a
• Documentation Installation Guiden/a
• Documentation Literaturen/a
• Documentation Maintenancen/a
• Documentation Technicaln/a
• Duration UnitYears
• EcojoyNo
• Expected Life0
• Featuresflushing cistern GD 2 with connections for GROHE Sensia. shower toilets (GROHE Sensia IGS/GROHE Sensia Arena). with maintenance access. 1.13 m finished installation height. for on-the-wall installations or studded walls. powder coated steel frame, self-supporting. for dry-cladding, completely pre-assembled. with fixed connections. for single or series installation. quick adjustment, lockable. fixing material. TÜV approved. 2 WC fixing bolts. fixing device for ceramic. distance of fixing bolts 180/230 mm. PP outlet bend Ø 90 mm. depth adjustable. reducer Ø 90/110 mm. inlet and outlet connecting set. flushing cistern GD 2, 6 - 3 l. pneumatic discharge valve offering 2 modes of operation: dual flush or single flush. rear water supply. low noise (group I acc. to German Noise Specification). Insulated against condensation. ½" water supply connection including integrated. angle valve and push fit flexible hose union. no tools required for the installation. of the inspection shaft incl. protection. during construction phase. for vertical or horizontal use. 2 wall brackets with fixing material. universal water connection for shower toilets Sensia Arena and Sensia IGS. concealed socket for mains supply. positioning help for electrical connection. for mounting of small flush plates please order. revision shaft 40 911 000 (sold separately).
• FinishPlastic & Metal
• Graden/a
• Hot Water Connection Diameter10 mm
• HW ConnectionNo
• HWFU4.5
• Ifc Export AsIfcPipeFitting
• Ifc Export TypeIfcPipeFittingType
• Industry Standardsn/a
• KeynoteN13
• LEED Creditn/a
• Low Emitting MaterialNo
• ManufacturerGrohe Limited
• Manufacturer NameGrohe Limited
• Masterformat Number01 52 19
• Masterformat TitleSanitary Facilities
• MaterialPlastic & Metal
• ModelRapid SL for GROHE Sensia® IGS & Arena shower WC
• Model Number39112001
• Model ReferenceRapid SL for GROHE Sensia® IGS & Arena shower WC
• NBS DescriptionUrinal flushing valves
• NBS Object NameGrohe Limited - Urinal flushing valves
• NBS Office Master Tagn/a
• NBS Reference45-35-70/355
• Nominal Depth0 mm
• Nominal Height0 mm
• Nominal Length0 mm
• Percentage Of Recycled Contentn/a
• Product Documentation Linkwww.grohe.co.uk/en_gb/rapid-sl-rapid-sl-for-grohe-sensia-igs-amp-arena-shower-wc-39112001.html
• Production Year2017
• Product Page URLwww.grohe.co.uk/en_gb/rapid-sl-rapid-sl-for-grohe-sensia-igs-amp-arena-shower-wc-39112001.html
• Referenced Standardn/a
• Replacement Costn/a
• Shapen/a
• Sizen/a
• Spare Partsn/a
• Type Comments39112001
• Type NameRapid SL for GROHE Sensia® IGS & Arena shower WC
• URLwww.grohe.com
• Vent ConnectionNo
• Warranty Descriptionn/a
• Warranty Duration Laborn/a
• Warranty Duration Partsn/a
• Warranty Duration UnitYears
• Warranty Guarantor Laborinfo-uk@grohe.com
• Warranty Guarantor Partsinfo-uk@grohe.com
• Waste ConnectionNo
• WFU0
