Grohe Plus Single-Lever Basin Mixer 1/2“ S-Size - 23870003

Description

single hole installation
metal lever
GROHE SilkMove ES 28 mm ceramic cartridge with energy saving function via cold start
with temperature limiter
GROHE StarLight chrome finish
GROHE EcoJoy SpeedClean mousseur 5.7 l/min
GROHE AquaGuide adjustable mousseur
GROHE QuickFix Plus installation system
pop-up waste set 1 1/4“
flexible connection hoses

Object Data

1 Revision

Last Updated

09/08/2019

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Maintenance Information

Technical Data Sheet

Object metadata

_AuthorJack Yellop
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility Performancen/a
Assembly CodeC1030
Asset TypeFixed
BIM Object NameGrohe_PlumbingFixtures_PlusSingle-leverBasinMixerS_23870003
Classification NameUniclass2015
Classification ValuePr_40_20_87_96
Code Performancen/a
ColorSilver
Constituentsn/a
Created Byinfo-uk@grohe.com
Created On2019-04-29T09:00:00
CW ConnectionYes
CWFU4.5
Default Elevation0 mm
Descriptionsingle hole installation, metal lever, GROHE SilkMove ES 28 mm ceramic cartridge, with energy saving function via cold start, with temperature limiter, GROHE StarLight chrome finish, GROHE EcoJoy SpeedClean mousseur 5.7 l/min, GROHE AquaGuide adjustable mousseur, GROHE QuickFix Plus installation system, pop-up waste set 1 1/4“, flexible connection hoses
Documentation Certificatesn/a
Documentation Installation Guiden/a
Documentation Literaturen/a
Documentation Maintenancen/a
Documentation Technicaln/a
Duration UnitYears
Expected Life0
Featuressingle hole installation, metal lever, GROHE SilkMove ES 28 mm ceramic cartridge, with energy saving function via cold start, with temperature limiter, GROHE StarLight chrome finish, GROHE EcoJoy SpeedClean mousseur 5.7 l/min, GROHE AquaGuide adjustable mousseur, GROHE QuickFix Plus installation system, pop-up waste set 1 1/4“, flexible connection hoses
FinishChrome
Graden/a
HW ConnectionYes
HWFU4.5
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
KeynoteN13
ManufacturerGrohe
Manufacturer NameGrohe
MaterialChrome
ModelPlus Single-lever basin mixer 1/2" S-Size
Model Number23870003
Model ReferencePlus Single-lever basin mixer 1/2" S-Size
NBS DescriptionWater supply fittings for wash basins and troughs
NBS Object NameGrohe - Water supply fittings for wash basins and troughs
NBS Office Master Tagn/a
NBS Reference45-35-70/371
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Primary FinishGrohe- Chrome
Production Year2019
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsn/a
Type Comments23870003
Type NamePlus Single-lever basin mixer 1/2" S-Size
URLwww.grohe.co.uk/en_gb/
Vent ConnectionNo
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborn/a
Warranty Guarantor Partsinfo-uk@grohe.com
Waste ConnectionNo
