Grohe Grohtherm Special Thermostatic Bath / Shower Mixer - 34671000

Description

wall or deck mountedergonomic handlesAquadimmer handle with multiple functionflow controlintegrated mixed water shut offdiverter bath/showerGROHE TurboStat compact cartridgewith wax thermoelementtemperature scale handle with pre-adjustablesafety stop between 35°C and 43°Ceasy thermal disinfection via optional key 47 994 000shower bottom outlet 1/2" withintegrated non return-valvemetal temperature safety stoplaminar mousseurdirt strainerswithout S-unions and coversGROHE Quickfix for fast exchange of non return valves in connectionsGROHE CoolTouch safety housingGROHE StarLight chrome finishGROHE SafetyPlus

This download is a face based plumbing fixture component created by bimstore.co.uk for Grohe.

This component is created in Revit 2015 for use in MEP systems and is in line with 2015 industry standards.

Object Data

1 Revision

Last Updated

24/05/2017

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

_AuthorRyan Lashley
_Authorized ByKris Atkinson
_Bim Spec Guid0
_BS Bible Version14
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility Performancen/a
ADA CompliantNo
Assembly CodeD2010
Asset TypeFixed
BIM Object NamePlumbingFixture_GroheLimited_ShowerMixer_34671000_METRIC
Classification NameUniclass2015
Classification ValuePr_40_20_87_07
Code Performancen/a
Cold Water Connection Diameter10 mm
ColorChrome
Constituentsn/a
Contact GroheGROHE Limited, World Business Centre 2, Newall Road, London Heathrow Airport, Hounslow, Middlesex, TW6 2SF - Tel: +44 (0) 871 200 3414 - Fax: +44 (0) 871 200 3415 - Email: info-uk@grohe.com
Created Byinfo-uk@grohe.com
Created On2017-05-08T00:00:00
CW ConnectionYes
CWFU4.5
Default Elevation0 mm
Descriptionwall or deck mounted. ergonomic handles. Aquadimmer handle with multiple function. flow control. integrated mixed water shut off. diverter bath/shower. GROHE TurboStat compact cartridge. with wax thermoelement. temperature scale handle with pre-adjustable. safety stop between 35°C and 43°C. easy thermal disinfection via optional key 47 994 000. shower bottom outlet 1/2" with. integrated non return-valve. metal temperature safety stop. laminar mousseur. dirt strainers. without S-unions and covers. GROHE Quickfix for fast exchange of non return valves in connections. GROHE CoolTouch safety housing. GROHE StarLight chrome finish. GROHE SafetyPlus.
Documentation Certificatesn/a
Documentation Installation Guiden/a
Documentation Literaturen/a
Documentation Maintenancen/a
Documentation Technicaln/a
Duration UnitYears
EcojoyNo
Expected Life0
Featureswall or deck mounted. ergonomic handles. Aquadimmer handle with multiple function. flow control. integrated mixed water shut off. diverter bath/shower. GROHE TurboStat compact cartridge. with wax thermoelement. temperature scale handle with pre-adjustable. safety stop between 35°C and 43°C. easy thermal disinfection via optional key 47 994 000. shower bottom outlet 1/2" with. integrated non return-valve. metal temperature safety stop. laminar mousseur. dirt strainers. without S-unions and covers. GROHE Quickfix for fast exchange of non return valves in connections. GROHE CoolTouch safety housing. GROHE StarLight chrome finish. GROHE SafetyPlus.
FinishChrome
Graden/a
Hot Water Connection Diameter10 mm
HW ConnectionYes
HWFU4.5
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
Industry Standardsn/a
KeynoteN13
LEED Creditn/a
Low Emitting MaterialNo
ManufacturerGrohe Limited
Manufacturer NameGrohe Limited
Masterformat Number01 52 19
Masterformat TitleSanitary Facilities
MaterialChrome
ModelGrohtherm Special Thermostatic bath/shower mixer 1/2"
Model Number34671000
Model ReferenceGrohtherm Special Thermostatic bath/shower mixer 1/2"
NBS DescriptionWater supply fittings for baths
NBS Object NameGrohe Limited - Water supply fittings for baths
NBS Office Master Tagn/a
NBS Reference45-35-70/315
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Percentage Of Recycled Contentn/a
Primary MaterialGrohe-Chrome-Polished
Product Documentation Linkwww.grohe.co.uk/en_gb/thermostatic-bath-shower-mixer-1-2-34671000.html
Production Year2017
Product Page URLwww.grohe.co.uk/en_gb/thermostatic-bath-shower-mixer-1-2-34671000.html
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsn/a
Type Comments34671000
Type NameGrohtherm Special Thermostatic bath/shower mixer 1/2"
URLwww.grohe.com
Vent ConnectionNo
Warranty Descriptionn/a
Warranty Duration Laborn/a
Warranty Duration Partsn/a
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com
Waste ConnectionNo
WFU0
