Grohe Grohtherm 1000 Cosmopolitan M - Thermostatic Shower Mixer - 34440002

Object metadata

• _authorized byKris Atkinson
• _BIMspec_GUID0
• _created byRyan Lashley
• _current revision1
• _distributed bywww.bimstore.co.uk
• ADA CompliantNo
• Assembly CodeC1030220
• Asset TypeFixed
• Classification NameUniclass 2015
• Classification ValuePr_40_20_87_78
• Cold Water Connection Diameter10 mm
• ColorChrome
• Contact GroheGROHE Limited, World Business Centre 2, Newall Road, London Heathrow Airport, Hounslow, Middlesex, TW6 2SF - Tel: +44 (0) 871 200 3414 - Fax: +44 (0) 871 200 3415 - EMail: info-uk@grohe.com
• Created Byinfo-uk@grohe.com
• Created OnMarch 2016
• CW ConnectionYes
• CWFU4.5
• Default Elevation600 mm
• Descriptionwall mounted. volume handle with GROHE EcoButton (economy button with individually adjustable economy stop). integrated mixed water shut off. ceramic headpart 1/2, 180°. shower bottom outlet 1/2. built-in non return valves. dirt strainers. S-unions. metal escutcheon. protected against backflow. min recommended pressure 1.0 bar
• Documentation Maintenancewww.grohe.co.uk/pim/profile/1000000/200000/40000/6000/900/220977.pdf
• Documentation Technicalwww.grohe.co.uk/pim/profile/1000000/000000/10000/9000/000/218925.pdf
• Duration UnitYears
• EcojoyYes
• Expected Life0
• Faucet MaterialGrohe-Chrome
• FeaturesGROHE StarLight® chrome finish. GROHE Turbostat® C3 compact cartridge with wax thermoelement. GROHE MetalGrip ergonomically shaped metal handles. GROHE SafeStop safety button at 38°C. GROHE SafeStop Plus integrated temperature limiter at max 50°C. GROHE EcoJoy® technology for less water and perfect flow
• FinishChrome
• Height70 mm
• Hot Water Connection Diameter10 mm
• HW ConnectionYes
• HWFU4.5
• Industry Standardsn/a
• KeynoteN13
• Length85 mm
• Low Emitting MaterialNo
• ManufacturerGrohe Limited
• Masterformat Number01 52 19
• Masterformat TitleSanitary Facilities
• MaterialChrome
• ModelGrohthrtm 1000 Cosmopolitan M - Thermostatic Shower Mixer
• Model NumberGrohthrtm 1000 Cosmopolitan M - 34440002
• NBS DescriptionShower mixers;
• NBS Object NameShower mixers;
• NBS Reference45-35-70/335
• Product Documentation Linkwww.grohe.co.uk/en_gb/grohtherm-1000-cosmopolitan-m-thermostatic-shower-mixer-1-2-34440002.html
• Product Page URLwww.grohe.co.uk/en_gb/grohtherm-1000-cosmopolitan-m-thermostatic-shower-mixer-1-2-34440002.html
• Production Year2016
• Size298x85x70mm
• Type CommentsGrohthrtm 1000 Cosmopolitan M - 34440002
• Type NameGrohthrtm 1000 Cosmopolitan M - Thermostatic Shower Mixer
• URLwww.grohe.com
• Vent ConnectionNo
• Warranty Duration UnitYears
• Waste ConnectionNo
• WFU0
• Width298 mm
