Grohe Eurostyle - Single-Lever Basin Mixer M-Size - 23564003

3.2k
0
- / 5
Rate this product

-

Compliant

BS1192:4

Compliant

BSB

Compliant

Object Data

1 Revision

Last Updated

22/03/2016

Download BIM

Add to collection

Available for:

GROHE SilkMove® 35 mm ceramic cartridge adjustable flow rate limiter with temperature limiter.

GROHE StarLight® chrome finish.

GROHE EcoJoy® mousseur 5.7 l/min.

GROHE Zero® isolated inner water ways - lead and nickel free.

GROHE QuickFix® rapid installation system

This download is a face based plumbing fixture component created by bimstore.co.uk for Grohe.

This component is created in Revit 2014 for use in MEP systems and is in line with 2015 industry standards.

_authorized byKris Atkinson
_BIMspec_GUID0
_created byRyan Lashley
_current revision1
_distributed bywww.bimstore.co.uk
ADA CompliantNo
Assembly CodeC1030220
Asset TypeFixed
Classification NameUniclass 2015
Classification ValuePr_40_20_87_96
Cold Water Connection Diameter10 mm
ColorChrome
Contact GroheGROHE Limited, World Business Centre 2, Newall Road, London Heathrow Airport, Hounslow, Middlesex, TW6 2SF - Tel: +44 (0) 871 200 3414 - Fax: +44 (0) 871 200 3415 - EMail: info-uk@grohe.com
Created Byinfo-uk@grohe.com
Created OnMarch 2016
CW ConnectionYes
CWFU4.5
Default Elevation600 mm
DescriptionEurostyle. Single-lever basin mixer 1/2 M-Size. single hole installation. metal lever. adjustable flow rate limiter. pop-up waste set 1 1/4. separate inner water ways – lead and nickel free. flexible connection hoses
Documentation Maintenanced3unq1hljpybmw.cloudfront.net/tpi/1000/1900/1940/1948/1948997/original/1948997.pdf
Documentation Technicald3unq1hljpybmw.cloudfront.net/tpi/1000/1900/1920/1922/1922243/original/1922243.pdf
Duration UnitYears
EcojoyYes
Expected Life0
Faucet MaterialGrohe-Chrome
FeaturesGROHE SilkMove® 35 mm ceramic cartridge adjustable flow rate limiter with temperature limiter. GROHE StarLight® chrome finish. GROHE EcoJoy® mousseur 5.7 l/min. GROHE Zero® isolated inner water ways - lead and nickel free. GROHE QuickFix® rapid installation system
FinishChrome
Height210 mm
Hot Water Connection Diameter10 mm
HW ConnectionYes
HWFU4.5
Industry Standardsn/a
KeynoteN13
Length0 mm
Low Emitting MaterialNo
ManufacturerGrohe Limited
Masterformat Number01 52 19
Masterformat TitleSanitary Facilities
MaterialChrome
ModelEurostyle - Single-Lever Basin Mixer M-Size
Model NumberEurostyle - 23564003
NBS DescriptionWater supply fittings for wash basins and troughs;
NBS Object NameWater supply fittings for wash basins and troughs;
NBS Reference45-35-70/371
Product Documentation Linkwww.grohe.com/30898/search/search-result/product-details/?product=23564-G433&color=003&material=23564003
Product Page URLwww.grohe.com/30898/search/search-result/product-details/?product=23564-G433&color=003&material=23564003
Production Year2016
SizeHeight 210mm
Type CommentsEurostyle - 23564003
Type NameEurostyle - Single-Lever Basin Mixer M-Size
URLwww.grohe.com
Vent ConnectionNo
Warranty Duration UnitYears
Waste ConnectionNo
WFU0
Width0 mm
