Grohe Eurosmart Single-Lever Basin Mixer - 33265001

4.4k
0
- / 5
Rate this product

-

Compliant

BS1192:4

Compliant

BSB

Compliant

Object Data

1 Revision

Last Updated

09/09/2015

Download BIM

Add to collection

Available for:

EurosmartSingle-lever basin mixer 1/2"single hole installationGROHE SilkMove® 35 mm ceramic cartridgeGROHE StarLight® chrome finish metal lever adjustable flow rate limiter mousseur pop-up waste set 1 1/4" flexible connection hoses rapid installation system optional temperature limiter ref. no. 46 375 noise classification 1 in accordance with DIN4109

This download is a face based plumbing fixture component created by bimstore.co.uk for Grohe.

This component is created in Revit 2014 for use in MEP systems and is in line with 2015 industry standards.

_authorized byConnor Laing
_BIMspec_GUID0
_created bybimstore
_current revision2
_distributed bywww.bimstore.co.uk
ADA CompliantYes
Assembly CodeC1030220
Asset TypeFixed
Classification NameUniclass2015
Classification ValuePr_40_20_87_98
Cold Water Connection Diameter10 mm
Cold Water Radius5 mm
ColorChrome
Contact GroheGROHE Limited, World Business Centre 2, Newall Road, London Heathrow Airport, Hounslow, Middlesex, TW6 2SF - Tel: +44 (0) 871 200 3414 - Fax: +44 (0) 871 200 3415 - EMail: info-uk@grohe.com
Created Byinfo-uk@grohe.com
Created OnJuly 13 - Revised August 2015
CW ConnectionYes
CWFU4.5
Default Elevation600 mm
DescriptionFeaturing a solid metal handle and forward-leaning dynamic lines, Eurosmart is the perfect addition to all contemporary bathroom settings. This high-quality faucet incorporates GROHE SilkMove® for smooth handling and GROHE StarLight® chrome for a lifelong shine. A basin mixer, with the latest GROHE EcoJoy technology, reduces water consumption to a maximum of 5.8 liters per minute.
Documentation Certificateswww.grohe.com/cy/11112/bathroom/bathroom-faucets/eurosmart/product-details/?product=33265-G154&color=001&material=33265001
Documentation Installation Guidewww.grohe.com/cy/11112/bathroom/bathroom-faucets/eurosmart/product-details/?product=33265-G154&color=001&material=33265001
Documentation Literaturecdn08.grohe.com/lib/1/tpi/1659281.pdf
Documentation Maintenanceprojects.grohe.com/lib/1/tpi/1734224.pdf
Documentation Technicalcdn08.grohe.com/lib/1/tpi/1659281.pdf
Duration UnitYears
EcojoyNo
Expected Life0
FinishChrome
Flow Pressuremin 0.5 bar/recommended 1 - 5 bar
Flow Rate13 L/min
Height124 mm
Hot Water Connection Diameter10 mm
Hot Water Radius5 mm
HW ConnectionYes
HWFU4.5
Industry StandardsN/A
KeynoteN13
Length160 mm
Low Emitting MaterialYes
ManufacturerGrohe AG
MaterialChrome
Mixing LeaverYes
ModelEurosmart Basin Mixer - 33265001
Model Number33265001
NameEurosmart Basin Mixer - 33265001
NBS DescriptionWater supply fittings for wash basins and troughs
NBS Object NameWashbasin taps
NBS Reference45-35-70/371
Operating Pressuremax 10 bar
Percentage of Recycled Content0
Product Documentation Linkcdn08.grohe.com/lib/1/tpi/1659281.pdf
Product Page URLwww.grohe.com/cy/11112/bathroom/bathroom-faucets/eurosmart/product-details/?product=33265-G154&color=001&material=33265001
Production Year2015
Spare Parts Listwww.grohe.com/cy/11112/bathroom/bathroom-faucets/eurosmart/product-details/?product=33265-G154&color=001&material=33265001&%7E%5Bajax%5D=2266
Temp - Hot Water Supplymax 80°C
Temp - Hot Water Supply (Recommended)60°C
Test Pressure16 bar
Type CommentsSingle-lever basin mixer 1/2
Type NameSingle-lever basin mixer 1/2
URLwww.grohe.com
Vent ConnectionNo
Warranty InfomationN/A
Warranty Duration UnitYears
Waste ConnectionNo
WFU0
Width52 mm
