Grohe Eurosmart Control Unit - 36416000

3.3k
0
- / 5
Rate this product

-

Compliant

BS1192:4

Compliant

BSB

Compliant

Object Data

1 Revision

Last Updated

24/05/2017

Download BIM

Add to collection

Available for:

for showerwith integrated pre-adjustablethermostatic mixersuitable for IR-set 36 415 0002 stop valvesGrohtherm Micro integratednon-return valves with filtersconnection housing for power supply

This download is a face based plumbing fixture component created by bimstore.co.uk for Grohe.

This component is created in Revit 2015 for use in MEP systems and is in line with 2015 industry standards.

Object metadata

_AuthorRyan Lashley
_Authorized ByKris Atkinson
_Bim Spec Guid0
_BS Bible Version14
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility Performancen/a
ADA CompliantNo
Assembly CodeD2010
Asset TypeFixed
BIM Object NamePlumbingFixture_GroheLimited_ControlUnit_36416000_METRIC
Classification NameUniclass2015
Classification ValuePr_40_20_93_79
Code Performancen/a
Cold Water Connection Diameter10 mm
ColorBlue
Constituentsn/a
Contact GroheGROHE Limited, World Business Centre 2, Newall Road, London Heathrow Airport, Hounslow, Middlesex, TW6 2SF - Tel: +44 (0) 871 200 3414 - Fax: +44 (0) 871 200 3415 - Email: info-uk@grohe.com
Created Byinfo-uk@grohe.com
Created On2017-05-08T00:00:00
CW ConnectionNo
CWFU4.5
Default Elevation0 mm
Descriptionfor shower. with integrated pre-adjustable. thermostatic mixer. suitable for IR-set 36 415 000. 2 stop valves. Grohtherm Micro integrated. non-return valves with filters. connection housing for power supply.
Documentation Certificatesn/a
Documentation Installation Guiden/a
Documentation Literaturen/a
Documentation Maintenancen/a
Documentation Technicaln/a
Duration UnitYears
EcojoyNo
Expected Life0
Featuresfor shower. with integrated pre-adjustable. thermostatic mixer. suitable for IR-set 36 415 000. 2 stop valves. Grohtherm Micro integrated. non-return valves with filters. connection housing for power supply.
FinishPlastic
Graden/a
Hot Water Connection Diameter10 mm
HW ConnectionNo
HWFU4.5
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
Industry Standardsn/a
KeynoteN13
LEED Creditn/a
Low Emitting MaterialNo
ManufacturerGrohe Limited
Manufacturer NameGrohe Limited
Masterformat Number01 52 19
Masterformat TitleSanitary Facilities
MaterialPlastic
ModelEurosmart Cosmopolitan E Concealed control unit
Model Number36416000
Model ReferenceEurosmart Cosmopolitan E Concealed control unit
NBS DescriptionUrinal flushing valves
NBS Object NameGrohe Limited - Urinal flushing valves
NBS Office Master Tagn/a
NBS Reference45-35-70/355
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Percentage Of Recycled Contentn/a
Primary MaterialGrohe-Plastic Casing (Blue)
Product Documentation Linkwww.grohe.co.uk/en_gb/eurosmart-cosmopolitan-e-concealed-control-unit-36416000.html
Production Year2017
Product Page URLwww.grohe.co.uk/en_gb/eurosmart-cosmopolitan-e-concealed-control-unit-36416000.html
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsn/a
Type Comments36416000
Type NameEurosmart Cosmopolitan E Concealed control unit
URLwww.grohe.com
Vent ConnectionNo
Warranty Descriptionn/a
Warranty Duration Laborn/a
Warranty Duration Partsn/a
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com
Waste ConnectionNo
WFU0
