bimstore - Grohe - Eurodisc Cosmopolitan - Single-lever bath/shower mixer 1/2″

562
0
- / 5
Rate this product

BS1192:4

Compliant

BSB

Compliant

Object Data

1 Revision

Last Updated

13/05/2021

Download BIM

Add to collection

Available for:

wall mounted
metal lever
GROHE SilkMove 46 mm ceramic cartridge
GROHE StarLight chrome finish
adjustable flow rate limiter
adjustable minimum flow rate 2.5 l/min
automatic diverter: bath/shower
mousseur
integrated non-return valve in the shower outlet 1/2"
S-unions
protected against backflow
optional temperature limiter (46 308 000)
noise classification 1 in accordance with DIN4109
with shower set
Consisting of:
hand shower euphoria 110 Champagne (27 222)
wall shower holder (27 056)
Relexaflex hose 1500 mm 1/2" x 1/2" (28 151)

_AuthorRL
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co
_Current Revision1
_Distributed Bywww.bimstore.co
_Object User Guidewww.bimstore.co/products/grohe-eurodisc-cosmopolitan-single-lever-bath-shower-mixer-1-2-33395002/document/object-user-guide
Accessibility Performancen/a
ADA CompliantNo
Assembly CodeD2010700
Asset Typen/a
BIM Object NameGrohe_PlumbingFixture_EurodiscCosmopolitan_SingleLeverBathShowerMixer_33395002
Classification NameUniclass 2015
Classification ValuePr_40_20_87_78
Code Performancen/a
Cold Water Connection Diameter10 mm
ColorChrome
Constituentsn/a
Contact Groheinfo-uk@grohe.com
Created Byinfo-uk@grohe.com
Created On2020-11-01T09:00:00
CWFU4.5
Default Elevation0 mm
Descriptionwall mounted metal lever GROHE SilkMove 46 mm ceramic cartridge GROHE StarLight chrome finish adjustable flow rate limiter adjustable minimum flow rate 2.5 l/min automatic diverter: bath/shower mousseur integrated non-return valve in the shower outlet 1/2" S-unions protected against backflow optional temperature limiter (46 308 000) noise classification 1 in accordance with DIN4109 with shower set Consisting of: hand shower euphoria 110 Champagne (27 222) wall shower holder (27 056) Relexaflex hose 1500 mm 1/2" x 1/2" (28 151)
Documentation Certificateswww.bimstore.co/products/grohe-eurodisc-cosmopolitan-single-lever-bath-shower-mixer-1-2-33395002/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/grohe-eurodisc-cosmopolitan-single-lever-bath-shower-mixer-1-2-33395002/document/installation-guide
Documentation Literaturewww.bimstore.co/products/grohe-eurodisc-cosmopolitan-single-lever-bath-shower-mixer-1-2-33395002/document/product-literature
Documentation Maintenancewww.bimstore.co/products/grohe-eurodisc-cosmopolitan-single-lever-bath-shower-mixer-1-2-33395002/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/grohe-eurodisc-cosmopolitan-single-lever-bath-shower-mixer-1-2-33395002/document/technical-data-sheet
Duration UnitYears
EcojoyNo
Expected Life0
Featureswall mounted metal lever GROHE SilkMove 46 mm ceramic cartridge GROHE StarLight chrome finish adjustable flow rate limiter adjustable minimum flow rate 2.5 l/min automatic diverter: bath/shower mousseur integrated non-return valve in the shower outlet 1/2" S-unions protected against backflow optional temperature limiter (46 308 000) noise classification 1 in accordance with DIN4109 with shower set Consisting of: hand shower euphoria 110 Champagne (27 222) wall shower holder (27 056) Relexaflex hose 1500 mm 1/2" x 1/2" (28 151)
Finishn/a
Graden/a
Hot Water Connection Diameter10 mm
HWFU4.5
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
Industry Standardsn/a
KeynoteN13
LEED Creditn/a
Low Emitting MaterialNo
ManufacturerGrohe
Manufacturer NameGrohe
Masterformat Number01 52 19
Masterformat TitleSanitary Facilities
Materialn/a
ModelEurodisc Cosmopolitan - Single-lever bath/shower mixer 1/2″
Model Number33395002
Model ReferenceEurodisc Cosmopolitan - Single-lever bath/shower mixer 1/2″
NBS DescriptionShower mixers
NBS Object NameGrohe - Shower mixers
NBS Office Master Tagn/a
NBS Reference45-35-70/335
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Percentage Of Recycled Contentn/a
Primary MaterialSteel, Chrome Plated
Product Documentation Linkwww.grohe.co.uk/en_gb/eurodisc-cosmopolitan-single-lever-bath-shower-mixer-1-2-33395002.html
Production Year2020
Product Page URLwww.grohe.co.uk/en_gb/eurodisc-cosmopolitan-single-lever-bath-shower-mixer-1-2-33395002.html
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsn/a
Type Comments33395002
Type NameEurodisc Cosmopolitan - Single-lever bath/shower mixer 1/2″
URLwww.grohe.co.uk/en_gb/
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com
