Grohe Euphoria System 260 - Shower system with thermostat for wall mounting - 27615001

by GROHE

Download Add to collection

Description

horizontal swivable 450 mm shower arm
exposed thermostat with Aquadimmer function
allows change between:
head shower Euphoria 260 (26 457)
3 spray patterns:
Rain, SmartRain, Jet
with ball joint, rotation angle ± 15°
hand shower Euphoria 110 Massage (27 239)
3 spray patterns:
Rain, SmartRain, Massage
adjustable in height with gliding element
Silverflex shower hose 1750 mm (28 388)
GROHE EcoJoy 9.5 l/min flow limiter
GROHE TurboStat compact cartridge with wax thermoelement
GROHE SafeStop safety button at 38°C
GROHE SafeStop Plus optional temperature limiter at 43°C included
GROHE DreamSpray perfect spray pattern
GROHE StarLight chrome finish
GROHE SprayDimmer (stepless flow rate reduction)
SpeedClean anti-lime system
Inner WaterGuide for a longer life
Twistfree to prevent hose from twisting
suitable for instantaneous heaters from 18 kW/h
minimum flow rate 7 l/min
min. recommended pressure 1.0 bar
optional upgrade: GROHE EasyReach tray (26 362), sold separately

Object Data

1 Revision

Last Updated

13/05/2021

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Product Data Sheet

Object metadata

_AuthorRL
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co
_Current Revision1
_Distributed Bywww.bimstore.co
_Object User Guidewww.bimstore.co/products/grohe-euphoria-system-260-shower-system-with-thermostat-for-wall-mounting-27615001/document/object-user-guide
Accessibility Performancen/a
ADA CompliantNo
Assembly CodeD2010700
Asset Typen/a
BIM Object NameGrohe_PlumbingFixture_EuphoriaSystem260_ShowerSystemWithThermostat_27615001
Classification NameUniclass 2015
Classification ValuePr_40_20_87_78
Code Performancen/a
Cold Water Connection Diameter10 mm
ColorChrome
Constituentsn/a
Contact Groheinfo-uk@grohe.com
Created Byinfo-uk@grohe.com
Created On2020-11-01T09:00:00
CWFU4.5
Default Elevation0 mm
DescriptionThe water saving GROHE Euphoria 260 shower system with thermostat adds instant designer style and showering enjoyment to any modern bathroom. Packed with GROHE’s cutting edge technology, top performance is guaranteed. Set your desired temperature with GROHE TurboStat and the water will stay just how you like it even if the supply fluctuates. The easy-to-use GROHE SafeStop feature limits the water temperature to a maximum of 38˚C – great for giving children independence in the bathroom – but can be raised for adults. The AquaDimmerlets you effortlessly control the volume of water while also directing the flow of water between the head and hand shower, which has a 1750mm TwistFree hose. GROHE EcoJoy limits water flow to 9.5 l/min but guarantees complete showering satisfaction and GROHE DreamSpray ensures the flow of water from every nozzle is even. The 260mm head shower comes with three distinctive spray zones. Jet Spray is powerful and focused, perfect for washing out shampoo and an invigorating head or neck massage.The SmartRain Spray is wider for an energizing yet relaxing experience and Rain Spray uses all the nozzles on the generous spray plate for full body coverage and a truly soothing shower. To choose the spray you want all you have to do is turn the ergonomic button on the spray head. And the 450mm shower arm even swivels through 180° for added flexibility. The 110mm hand shower also has three sprays: the soft Rain, the water-saving SmartRain and the powerful Massage Spray. The handy silicone SpeedClean nozzles means the showers are easy to keep free of dirt and limescale! The multilayered coating of the durable GROHE StarLight chrome finish has a sparkle that lasts for years and the Inner WaterGuide prevents the surface of the shower from getting hot. The GROHE Euphoria 260 shower system – all-round showering perfection!
Documentation Certificateswww.bimstore.co/products/grohe-euphoria-system-260-shower-system-with-thermostat-for-wall-mounting-27615001/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/grohe-euphoria-system-260-shower-system-with-thermostat-for-wall-mounting-27615001/document/installation-guide
Documentation Literaturewww.bimstore.co/products/grohe-euphoria-system-260-shower-system-with-thermostat-for-wall-mounting-27615001/document/product-literature
Documentation Maintenancewww.bimstore.co/products/grohe-euphoria-system-260-shower-system-with-thermostat-for-wall-mounting-27615001/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/grohe-euphoria-system-260-shower-system-with-thermostat-for-wall-mounting-27615001/document/technical-data-sheet
Duration UnitYears
EcojoyNo
Expected Life0
FeaturesThe water saving GROHE Euphoria 260 shower system with thermostat adds instant designer style and showering enjoyment to any modern bathroom. Packed with GROHE’s cutting edge technology, top performance is guaranteed. Set your desired temperature with GROHE TurboStat and the water will stay just how you like it even if the supply fluctuates. The easy-to-use GROHE SafeStop feature limits the water temperature to a maximum of 38˚C – great for giving children independence in the bathroom – but can be raised for adults. The AquaDimmerlets you effortlessly control the volume of water while also directing the flow of water between the head and hand shower, which has a 1750mm TwistFree hose. GROHE EcoJoy limits water flow to 9.5 l/min but guarantees complete showering satisfaction and GROHE DreamSpray ensures the flow of water from every nozzle is even. The 260mm head shower comes with three distinctive spray zones. Jet Spray is powerful and focused, perfect for washing out shampoo and an invigorating head or neck massage.The SmartRain Spray is wider for an energizing yet relaxing experience and Rain Spray uses all the nozzles on the generous spray plate for full body coverage and a truly soothing shower. To choose the spray you want all you have to do is turn the ergonomic button on the spray head. And the 450mm shower arm even swivels through 180° for added flexibility. The 110mm hand shower also has three sprays: the soft Rain, the water-saving SmartRain and the powerful Massage Spray. The handy silicone SpeedClean nozzles means the showers are easy to keep free of dirt and limescale! The multilayered coating of the durable GROHE StarLight chrome finish has a sparkle that lasts for years and the Inner WaterGuide prevents the surface of the shower from getting hot. The GROHE Euphoria 260 shower system – all-round showering perfection!
Finishn/a
Graden/a
Hot Water Connection Diameter10 mm
HWFU4.5
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
Industry Standardsn/a
KeynoteN13
LEED Creditn/a
Low Emitting MaterialNo
ManufacturerGrohe
Manufacturer NameGrohe
Masterformat Number01 52 19
Masterformat TitleSanitary Facilities
Materialn/a
ModelEuphoria System 260 - Shower system with thermostat for wall mounting
Model Number27615001
Model ReferenceEuphoria System 260 - Shower system with thermostat for wall mounting
NBS DescriptionShower mixers
NBS Object NameGrohe - Shower mixers
NBS Office Master Tagn/a
NBS Reference45-35-70/335
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Percentage Of Recycled Contentn/a
Primary MaterialSteel, Chrome Plated
Product Documentation Linkwww.grohe.co.uk/en_gb/euphoria-shower-system-shower-system-with-thermostat-for-wall-mounting-27615001.html
Production Year2020
Product Page URLwww.grohe.co.uk/en_gb/euphoria-shower-system-shower-system-with-thermostat-for-wall-mounting-27615001.html
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsn/a
Type Comments27615001
Type NameEuphoria System 260 - Shower system with thermostat for wall mounting
URLwww.grohe.co.uk/en_gb/
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com
