Grohe Euphoria - 110 Massage Shower Rail - 27226001

3.7k
0
- / 5
Rate this product

-

Compliant

BS1192:4

Compliant

BSB

Compliant

Object Data

1 Revision

Last Updated

19/07/2017

Download BIM

Add to collection

Available for:

Euphoria 110 MassageShower rail set 3 spraysconsisting of:hand shower Massage (27 221 000)shower rail 900 mm (27 500 000)Silverflex shower hose 1750 mm (28 388)GROHE EasyReach tray (27 596 000)GROHE DreamSpray perfect spray patternGROHE StarLight chrome finishGROHE SprayDimmer (Stepless flow rate reduction)GROHE QuickFix (upper bracket adjustable for adaption to existing drilling holes)SpeedClean anti-lime systemInner WaterGuide for a longer lifeTwistfree to prevent hose from twisting

This download is a face based plumbing fixture component created by bimstore.co.uk for Grohe.

This component is created in Revit 2015 for use in MEP systems and is in line with 2015 industry standards.

_AuthorRW
_Authorized ByKris Atkinson
_Bim Spec Guid0
_BS Bible Version14
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility Performancen/a
ADA CompliantNo
Assembly CodeD2010
Asset TypeFixed
BIM Object NamePlumbingFixture_GroheLimited_Euphoria_110MassageShowerRailSet_27226001_METRIC
Classification NameUniclass2015
Classification ValuePr_40_20_87_78
Code Performancen/a
Cold Water Connection Diameter20 mm
ColorChrome
Constituentsn/a
Created Byinfo-uk@grohe.com
Created On2017-06-01T09:00:00
CW ConnectionYes
CWFU4.5
Default Elevation0 mm
DescriptionEuphoria 110 Massage Shower rail set 3 sprays consisting of: hand shower Massage (27 221 000) shower rail 900 mm (27 500 000) Silverflex shower hose 1750 mm (28 388) GROHE EasyReach tray (27 596 000) GROHE DreamSpray perfect spray pattern GROHE StarLight chrome finish GROHE SprayDimmer (Stepless flow rate reduction) GROHE QuickFix (upper bracket adjustable for adaption to existing drilling holes) SpeedClean anti-lime system Inner WaterGuide for a longer life Twistfree to prevent hose from twisting
Documentation Certificatesn/a
Documentation Installation Guiden/a
Documentation Literaturen/a
Documentation Maintenancen/a
Documentation Technicaln/a
Duration UnitYears
EcojoyNo
Expected Life0
FeaturesEuphoria 110 Massage Shower rail set 3 sprays consisting of: hand shower Massage (27 221 000) shower rail 900 mm (27 500 000) Silverflex shower hose 1750 mm (28 388) GROHE EasyReach tray (27 596 000) GROHE DreamSpray perfect spray pattern GROHE StarLight chrome finish GROHE SprayDimmer (Stepless flow rate reduction) GROHE QuickFix (upper bracket adjustable for adaption to existing drilling holes) SpeedClean anti-lime system Inner WaterGuide for a longer life Twistfree to prevent hose from twisting
FinishChrome
Graden/a
Hot Water Connection Diameter20 mm
HW ConnectionYes
HWFU4.5
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
Industry Standardsn/a
KeynoteN13
LEED Creditn/a
Low Emitting MaterialNo
ManufacturerGrohe Limited
Manufacturer NameGrohe Limited
Masterformat Number01 52 19
Masterformat TitleSanitary Facilities
MaterialChrome
ModelEuphoria 110 Massage Shower rail set 3 sprays
Model Number27226001
Model ReferenceEuphoria 110 Massage Shower rail set 3 sprays
NBS DescriptionShower manual water supply sets
NBS Object NameGrohe Limited - Shower mixers
NBS Office Master Tagn/a
NBS Reference45-35-70/335
Nominal Depth112 mm
Nominal Height770 mm
Nominal Length81 mm
Percentage Of Recycled Contentn/a
Pipe MaterialGroheLimited-Pipework
Primary MaterialGroheLimited-Chrome
Product Documentation Linkcdn.cloud.grohe.com/tpi/1000/1900/1990/1995/1995873/original/1995873.pdf
Production Year2017
Product Page URLwww.grohe.co.uk/en_gb/euphoria-shower-rail-set-3-sprays-27226001.html
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsn/a
Type Comments27226001
Type NameEuphoria 110 Massage Shower rail set 3 sprays
URLwww.grohe.com
Vent ConnectionNo
Warranty Descriptionn/a
Warranty Duration Laborn/a
Warranty Duration Partsn/a
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com
Waste ConnectionNo
WFU0
