Grohe Bau Cosmopolitan E Infra-Red Electronic Basin Mixer 1/2" With Mixing Device and Temperature Limiter - 36453000

Download Add to collection

Description

with infrared sensor for bi-directional communication
for monitoring, configuration and servicing
with plug transformer 100-230 V AC, 50-60 Hz, 6 V DC
GROHE StarLight chrome finish
GROHE EcoJoy mousseur 5.7 l/min
GROHE Zero isolated inner water ways - lead and nickel free
body made of composite polymer
flexible connection hoses
non-return valve
dirt strainers
with integrated solenoid valve
rapid installation system
7 pre-set programs:
auto flush
thermal disinfection
cleaning mode
additional functions and precise settings by remote control 36 407
CE approved
noise classification I in accordance with DIN 4109

Object Data

1 Revision

Last Updated

30/04/2020

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Product Data Sheet

Object metadata

_AuthorRL
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version15
_Created Bywww.bimstore.co
_Current Revision1
_Distributed Bywww.bimstore.co
Accessibility Performancen/a
ADA CompliantNo
Assembly CodeC1030
Asset TypeFixed
BIM Object NameGrohe_PlumbingFixtures_BasinMixer_Eurosmart_36453000
Classification NameUniclass2015
Classification ValuePr_40_20_87_96
Code Performancen/a
Cold Water Connection Diameter10 mm
ColorSilver
Constituentsn/a
Created Byinfo-uk@grohe.com
Created On2020-02-01T09:00:00
CW ConnectionYes
CWFU4.5
Default Elevation0 mm
Descriptionwith infrared sensor for bi-directional communication. for monitoring, configuration and servicing. with plug transformer 100-230 V AC, 50-60 Hz, 6 V DC. GROHE StarLight chrome finish. GROHE EcoJoy mousseur 5.7 l/min. GROHE Zero isolated inner water ways - lead and nickel free. body made of composite polymer. flexible connection hoses. non-return valve. dirt strainers. with integrated solenoid valve. rapid installation system. 7 pre-set programs:. auto flush. thermal disinfection. cleaning mode. additional functions and precise settings by remote control 36 407. CE approved. noise classification I in accordance with DIN 4109.
Documentation Certificateswww.grohe.com/
Documentation Installation Guidewww.grohe.com/
Documentation Literaturewww.grohe.com/
Documentation Maintenancewww.grohe.com/
Documentation Technicalwww.grohe.com/
Duration UnitYears
EcojoyNo
Expected Life0
Faucet MaterialGrohe-Chrome
Featureswith infrared sensor for bi-directional communication. for monitoring, configuration and servicing. with plug transformer 100-230 V AC, 50-60 Hz, 6 V DC. GROHE StarLight chrome finish. GROHE EcoJoy mousseur 5.7 l/min. GROHE Zero isolated inner water ways - lead and nickel free. body made of composite polymer. flexible connection hoses. non-return valve. dirt strainers. with integrated solenoid valve. rapid installation system. 7 pre-set programs:. auto flush. thermal disinfection. cleaning mode. additional functions and precise settings by remote control 36 407. CE approved. noise classification I in accordance with DIN 4109.
FinishStarLight Chrome
Graden/a
Hot Water Connection Diameter10 mm
HW ConnectionYes
HWFU4.5
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
Industry Standardsn/a
KeynoteN13
LEED Creditn/a
Low Emitting MaterialNo
ManufacturerGrohe
Manufacturer NameGrohe
Masterformat Number01 52 19
Masterformat TitleSanitary Facilities
MaterialStarLight Chrome
ModelBau Cosmopolitan E Infra-red electronic basin mixer 1/2" with mixing device and temperature limiter
Model Number36453000
Model ReferenceBau Cosmopolitan E Infra-red electronic basin mixer 1/2" with mixing device and temperature limiter
NBS DescriptionWashbasin manual water supply sets
NBS Object NameGrohe - Washbasin manual water supply sets
NBS Office Master Tagn/a
NBS Reference45-35-70/371
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Percentage Of Recycled Contentn/a
Product Documentation Linkn/a
Production Year2020
Product Page URLn/a
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsn/a
Type Comments36453000
Type Name36453000
URLwww.grohe.com
Vent ConnectionNo
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com
Waste ConnectionNo

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
