ATRIO Bath / shower mixer 1/2″ (25272KF0)

by GROHE

Download Add to collection

Description

Product Number - 25272KF0

EAN - n/a

Colour - Phantom Black

PRODUCT MAIN FEATURES

floor-mounted installation with high pillar unions (765 mm)
set for final installation for
45 984 001
ceramic headparts 1/2", 90°
GROHE Long-Life finish
automatic diverter: bath/shower
spout with mousseur
projection 301 mm
integrated non-return valve in the shower outlet 1/2"
hand shower Rainshower Aqua Stick (26 866)
with shower holder
Silverflex shower hose 1250 mm (28 362)
protected against backflow
with cross handles
without roughing-in set 45 984 (please order separately)
Two different sets of caps included. One set with "H" and "C" marking, one set without marking.

Product Page - n/a

Object Data

1 Revision

Last Updated

21/08/2025

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Data Sheet

Object metadata

_AuthorRL 200
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/0d08d2db-187f-48c6-abc9-9a3f00a1652c/document/object-user-guide
Accessibility Performancen/a
Assembly CodeD2010
Asset TypeFixed
BIM Object NameGrohe_BathMixer_25272KF0
Classification NameUniclass2015
Classification ValuePr_40_20_87_09
CO2 Neutral ProductionGROHE is one of the first leading manufacturer within the sanitary industry having a CO2-neutral production.
Code Performancen/a
ColorPhantom Black
Constituentsn/a
Cradle To Cradle CertificationN/A
Created Byinfo-uk@grohe.com
Created On2025-07-08T09:00:00
Default Elevation1219 mm
DescriptionBath Mixer 1/2" (25272KF0)
Dimensions Document Linkcdn.cloud.grohe.com/dimdraw/100000/100000/100000/100000/100030/100032/100032015/1280/100032015.jpg cdn.cloud.grohe.com/dimdraw/100000/100000/100000/100000/100090/100092/100092130/1280/100092130.jpg
Documentation Certificateswww.bimstore.co/products/0d08d2db-187f-48c6-abc9-9a3f00a1652c/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/0d08d2db-187f-48c6-abc9-9a3f00a1652c/document/installation-guide
Documentation Literaturewww.bimstore.co/products/0d08d2db-187f-48c6-abc9-9a3f00a1652c/document/product-literature
Documentation Maintenancewww.bimstore.co/products/0d08d2db-187f-48c6-abc9-9a3f00a1652c/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/0d08d2db-187f-48c6-abc9-9a3f00a1652c/document/technical-data-sheet
Duration UnitYears
EcojoyNo
EF000010Finishing section
EF000278not relevant
EF000958true
EF001469not relevant
EF002149false
EF002286Insert (push coupling)
EF002671Black
EF0054640
EF005474IP25
EF006974Manually operated
EF011779not applicable
EF01275322.00
EF014578true
EF014591true
EF015280not relevant
EF016712TRUE
EF016713TRUE
EF016714TRUE
EF016731Group I,<= 20 dB(A)
EF017097TRUE
EF020103false
EF020105Yes
EF020774true
EF020775false
EF020776false
EF020777false
EF020778false
EF020779false
EF020780Single-grip
EF020781Cartouche, ball
EF020782Stainless steel
EF020783Other
EF020784Other
EF020787Group II, <=30 dB(A)
EF020788true
EF020789301
EF020790true
EF020963true
EF021498TRUE
EF021855true
EF022042Z
EF022133false
EF022484true
EF023686Other
EF023687true
EF023957true
EF024921true
EF025098not applicable
EF025102not relevant
EFDE0022None
EFSE0002true
Expected Life0
Featuresn/a
FinishPhantom Black
Full Recyclability Of PlasticAll plastic components are fully recycable
Graden/a
GROHE Social Committmentgreen.grohe.com/social_engagement
GROHE Sustainabilityn/a
Ifc Export AsIfcSanitaryTerminalType
Ifc Export TypeBATH
KeynoteN13
ManufacturerGrohe
Manufacturer NameGrohe
Materialn/a
ModelBath Mixer 1/2" (25272KF0)
Model Number25272KF0
Model ReferenceBath Mixer 1/2" (25272KF0)
NBS DescriptionBath taps
NBS Noten/a
NBS Object NameVADO - Bath taps
NBS Office Master Tagn/a
NBS Reference45-35-70/315
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
PQ Diagram Linkcdn.cloud.grohe.com/PQCharts/lores/2/252/original/25272KF0-pqchart-en_GB.svg
Primary MaterialGrohe_PhantomBlack
Product Descriptionfloor-mounted installation with high pillar unions (765 mm) set for final installation for 45 984 001 ceramic headparts 1/2", 90° automatic diverter: bath/shower spout with mousseur projection 301 mm integrated non-return valve in the shower outlet 1/2" hand shower Rainshower Aqua Stick (26 866) with shower holder Silverflex shower hose 1250 mm 1/2" x 1/2" (28 362) protected against backflow with cross handles without roughing-in set 45 984 (please order separately) Two different sets of caps included. One set with "H" and "C" marking, one set without marking.
Production Year2025
Product Number25272KF0
Product Page URLwww.grohe.co.uk/en_gb/-25272KF0.html
Product Short TextBath mixer 1/2"
Product TypeTwo Handle Fitting
Referenced Standardn/a
Replacement Costn/a
Secondary MaterialGrohe_White
Shapen/a
Sizen/a
Spare Partsinfo-uk@grohe.com
Sustainability Awardgreen.grohe.com/awards
Sustainability Reportgreen.grohe.com/reporting
TPI Document Linkcdn.cloud.grohe.com/tpi/2000/2200/2200/2205/2205667/original/2205667.pdf
Type CommentsBath Mixer 1/2" (25272KF0)
Type NameBath Mixer 1/2" (25272KF0)
URLwww.grohe.co.uk/
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
