WATM250001 Concentric Water Meter

Description

Reliance Valves Tenant Valve Advance Water Meter for primary charging of a cold water supply. The valve is a coaxial type and suited for direct connection to the Tenant Valve Advance. Acting as a sensitive positive displacement water meter, the valve features a rotating type impellor to reliably and accurately monitor the water supply usage. The flowing water causes the piston to rotate within its chamber, each piston revolution being the equivalent to a known volume of water. The piston movement is transferred by a magnetic coupling to the register, which has the appropriate reduction gearing. The water meter is tailor made for the UK market and its unique requirements.

Features and benefits

• Specially designed for high accuracy and wide measuring range
• Sealed super-dry register
• Designed to accept a clip on pulse output cap
• Lightweight composite body construction
• Suitable for use as a primary charging meter
• Vertical or horizontal installation
• Rotating dial allows orientation for easy reading
• MID Approved - R315 Product Description code
