Compression - Long Coupling

Download Add to collection

Description

BOSS Compression Long Coupling

Object Data

1 Revision

Last Updated

28/01/2020

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Installation Guide

Technical Data Sheet

Object metadata

_Authorwww.alusservices.co.uk
_Bim Spec Guid0
_BS Bible Version15
_Created Bywww.alusservices.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility PerformanceN/A
AF129 mm
AirNo
ApplicationCompression Long Coupling
ApprovalWRAS approved.
Assembly CodeD2090800
Asset TypeFixed
BIM Object NameBOSS_PipeFittings_Compression_LongCoupling
BodyDZR
Classification NameUniclass2015
Classification ValuePr_65_52_63_18
Code PerformanceN/A
ColorDZR
ConnectionCompression
ConstituentsN/A
Created Byenquiries@bssgroup.com
Created On27-12-2019 T09:00:00
D132 mm
D220 mm
D329 mm
DescriptionBOSS Compression Long Coupling 22mm
Documentation CertificatesN/A
Documentation Installation GuideN/A
Documentation LiteratureN/A
Documentation MaintenanceN/A
Documentation TechnicalN/A
Duration Unityears
EAN CodeN/A
Expected Life0
FeaturesFittings made from CW617N European brass material, Available in sizes 8 to 54 mm, Quality assured in accordance with ISO9001:2008 from BSI,WRAS approved, BSI Kite Mark approved, Designed for jointing EN 1057 copper tubes, Manufactured to EN 1254 Part 2.
FinishDZR
Gas CombustibleNo
Gas CorrosiveNo
Gas InertNo
Gas OxygenNo
GPID CodeN/A
GradeN/A
Hex VisYes
Ifc Export AsIfcPipeFittingType.JUNCTION
Ifc Export TypeIfcPipeFittingType
K Coefficient0
K Coefficient TableReducer/Coupling/Union/Increaser
KeynoteS
L151 mm
L251 mm
L337 mm
L437 mm
L548 mm
L648 mm
L711 mm
L811 mm
Loss MethodNot Defined
ManufacturerBSS BOSS Products
Manufacturer NameBSS BOSS Products
MaterialDZR
Maximum Working Pressure16 Bar
Maximum Working Temperature110°C
ModelBOSS Compression Long Coupling
Model Number62240548
Model ReferenceBOSS Compression Long Coupling 22mm
NBS DescriptionCopper pipeline fittings
NBS Object NameBSS BOSS Products -Copper pipeline fittings
NBS Office Master TagN/A
NBS Reference90-10-65/315
Nominal Depth37 mm
Nominal Dia22 mm
Nominal Height37 mm
Nominal Length102 mm
Nominal Width102 mm
Nut Left AF32 mm
Nut Right AF32 mm
Oct VisNo
OilNo
Pressure DropN/A
Production Year2019
Referenced StandardN/A
Replacement CostN/A
ShapeCylindrical
Size22mm
Spare PartsBOSS Technical Team Tel 0116 245 5940
SteamNo
Tubing OptionsCopper
Type CommentsBOSS Compression Long Coupling
Type NameBOSS Compression Long Coupling
URLwww.bssindustrial.co.uk/products/boss
Warranty DescriptionN/A
Warranty Duration Labor0
Warranty Duration Parts1
Warranty Duration Unityears
Warranty Guarantor Laborenquiries@bssgroup.com
Warranty Guarantor Partsenquiries@bssgroup.com
WaterYes
WeightN/A
Z127 mm
Z24 mm

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
