Cobalto Towel Radiator

Object metadata

• _AuthorAM
• _Authorized Bybimstore
• _Bim Spec Guid2
• _BS Bible Version17
• _Created Bywww.bimstore.co
• _Current Revision1
• _Distributed Bywww.bimstore.co
• Accessibility Performancen/a
• Assembly CodeD3020
• Asset TypeFixed
• BIM Object NameStelrad_MechanicalEquipment_TowelRadiator_Cobalto
• Bottom Arrray4
• Bottom Bar Offset38.20 mm
• Bottom Bracket Offset39.18 mm
• Btu/hr1707
• Classification NameUniclass2015
• Classification ValuePr_70_60_36_26
• Class Of ProtectionII
• Code Performancen/a
• ColorWhite
• Constituentsn/a
• ControlsOil filled
• Created Byinfo@stelrad.com
• Created On2024-01-11 T09:00:00
• Default Elevation0.00 mm
• DescriptionThis thermally efficient electric flat tube towel rail combines captivating, good looks with exceptional heating efficiency and offers a sensational solution for heating in the home. The towel rail is filled with a fluid which is heated up using an electrical element immersed in the fluid inside. This maintenance free and specially formulated fluid is designed to distribute the heat quickly and evenly across the towel radiator, which in turn emits the heat into your room through radiation.
• Documentation Certificateswww.bimstore.co/products/cobalto/document/product-certificates
• Documentation Installation Guidewww.bimstore.co/products/cobalto/document/installation-guide
• Documentation Literaturewww.bimstore.co/products/cobalto/document/product-literature
• Documentation Maintenancewww.bimstore.co/products/cobalto/document/maintenance-information
• Documentation Technicalwww.bimstore.co/products/cobalto/document/technical-data-sheet
• Duration UnitYear
• Expected Life0
• Featuresn/a
• Finishn/a
• Gap 1192.20 mm
• Gap 2423.20 mm
• Gap 3654.20 mm
• Graden/a
• Heat Output500 W
• Heat SourceIntegrated Control Panel
• Ifc Export AsIfcSpaceHeater
• Ifc Export TypeIfcSpaceHeaterTypeEnum.RADIATOR
• Indice Of ProtectionIP34
• KeynoteT
• ManufacturerStelrad
• Manufacturer NameStelrad
• Materialn/a
• Mid Arrray 12
• Mid Arrray 22
• ModelCobalto
• Model NumberCobalto
• Model Reference1413mm(H) x 500mm(L)
• NBS DescriptionElectric heated towel rails
• NBS Noten/a
• NBS Object NameStelrad - Electric heated towel rails
• NBS Office Master Tagn/a
• NBS Reference90-40-35/385
• Nominal Depth0.00 mm
• Nominal Height1090.00 mm
• Nominal Length500.00 mm
• Offset Gap77.00 mm
• Production Year2024
• Radiator FinishStelrad - Metal - White
• Referenced Standardn/a
• Replacement Costn/a
• Sizen/a
• Spare Partsn/a
• Top Arrray2
• Top Bar Offset38.20 mm
• Top Bracket Offset39.00 mm
• Type Comments1413mm(H) x 500mm(L)
• Type Name1413mm(H) x 500mm(L)
• UINE007-1090-0500
• Unit Height1076.00 mm
• URLwww.stelrad.com
• Voltage230 V~ 50 Hz
• Warranty Descriptionn/a
• Warranty Duration Labor0
• Warranty Duration Parts0
• Warranty Duration UnitYear
• Warranty Guarantor Laborn/a
• Warranty Guarantor Partsinfo@stelrad.com
• Weight16.10 kg
