CIVIC EC LB 300 - Heat Recovery Unit

by Blauberg UK Limited

Download Add to collection

Description

The CIVIC EC LB units are designed for single-room ventilation of schools, offices and other public and commercial premises.

Floor Standing

Automatic Summer Bypass

CO2, Humidity & Temperature Sensing

Objects Included:

CIVIC EC LB 300 S21
CIVIC EC LBE 300 S21
CIVIC EC LBE2 300 S21

Object Data

1 Revision

Last Updated

15/09/2021

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Installation Guide

Product Literature

Technical Data Sheet

Product Data Sheet

Object metadata

_Authortechnicalsupport@blauberg.co.uk
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.blauberg.co.uk/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/civic-ec-lb-3002/document/object-user-guide
Accessibility Performancen/a
Asset TypeFixed
BIM Object Nameblauberg_MechanicalEquipment_Civic_EC_LB3002
Casing MaterialPainted Steel White
Classification NameUniclass2015
Classification ValuePr_60_65_03_86
Code Performancen/a
Colorn/a
Constituentsn/a
Created Bytechnicalsupport@blauberg.co.uk
Created On2021-08-31T09:00:00
Current1 A
D1197 mm
DescriptionSingle-room heat recovery air handling unit
d L5 mm
Documentation Certificateswww.bimstore.co/products/civic-ec-lb-3002/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/civic-ec-lb-3002/document/installation-guide
Documentation Literaturewww.bimstore.co/products/civic-ec-lb-3002/document/product-literature
Documentation Maintenancewww.bimstore.co/products/civic-ec-lb-3002/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/civic-ec-lb-3002/document/technical-data-sheet
Drain Connection Diameter8 mm
Duct Connection Diameter200 mm
Duration UnitYears
d W5 mm
el Con Back90 mm
el Con Side170 mm
Expected Life0
Extract Air FilterG4x2
Featuresn/a
Finishn/a
Graden/a
Grid MaterialGrid Cross
H1762 mm
H11476 mm
H2286 mm
Hb100 mm
Hc1662 mm
Heat Exchanger Materialpolystyrene
Heat Exchanger Typecounter-flow
Heatrecoveryefficiency Percentage78..92
Ht13 mm
Ifc Export AsIfcEnergyConversionDeviceType
Ifc Export TypeIfcUnitaryEquipmentTypeEnum.AIRCONDITIONINGUNIT
L470 mm
L1520 mm
Load ClassificationHVAC
Maintenance Zone Front Depth600 mm
Maintenance Zone MaterialMaintenance Zone
Maintenance Zone Side Depth350 mm
ManufacturerBlauberg
Manufacturer NameBlauberg UK
Materialn/a
Maximum Air Flow320 m³/h
Maximum Unit Current With Electric Heater1 A
Maximum Unit Current Without Electric Heater1 A
Maximum Unit Power Without Electric Heater125 W
ModelCIVIC EC LB 300 S21
Model NumberCivic EC LB3002
Model ReferenceCIVIC EC LB 300 S21
NBS DescriptionSupply air handling units
NBS Object NameBlauberg UK - Air Handling Units
NBS Office Master Tagn/a
NBS Reference90-45-15/310
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Number Of Poles1
of H125 mm
of Left50 mm
of Left Center310 mm
of Right50 mm
of Right Center310 mm
of Top Of Center125 mm
of W520 mm
os Back70 mm
os H240 mm
os Top Of Center330 mm
os W310 mm
Power125 W
Power Factor1
Preheat Power0 W
Production Year2021
Referenced Standardn/a
Reheater Power0 W
Replacement Costn/a
RP Mmin 12150
SEC ClassA
Shapen/a
Sizen/a
Sound Pressure Levelat 1m DBA31
Sound Pressure Levelat 3m DBA21
Spare Partsn/a
Supply Air FilterG4+F8
Transported Air Temperature Degrees C–25 …+40
Type CommentsSingle-room heat recovery air handling unit CIVIC EC LB 300 S21
Type NameSingle-room heat recovery air handling unit CIVIC EC LB 300 S21
URLwww.blauberg.co.uk/
Voltage230 V
W620 mm
W1230 mm
W2195 mm
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborn/a
Warranty Guarantor Partstechnicalsupport@blauberg.co.uk
Weight138 kg
