CIVIC EC DB 1000 - Heat Recovery Unit

Object metadata

• _Authortechnicalsupport@blauberg.co.uk
• _Authorized Bybimstore
• _Bim Spec Guid0
• _BS Bible Version16
• _Created Bywww.blauberg.co.uk/
• _Current Revision1
• _Distributed Bywww.bimstore.co/
• _Object User Guidewww.bimstore.co/products/civic-ec-db-1000-s21/document/object-user-guide
• Accessibility Performancen/a
• Asset TypeFixed
• BIM Object Nameblauberg_MechanicalEquipment_Civic_EC_DB10002
• Casing MaterialPainted Steel White
• Classification NameUniclass2015
• Classification ValuePr_60_65_03_86
• Code Performancen/a
• Colorn/a
• Constituentsn/a
• Created Bytechnicalsupport@blauberg.co.uk
• Created On2021-08-31T09:00:00
• Current2 A
• D1312 mm
• DescriptionSingle-room ventilation unit
• d L5 mm
• Documentation Certificateswww.bimstore.co/products/civic-ec-db-1000-s21/document/product-certificates
• Documentation Installation Guidewww.bimstore.co/products/civic-ec-db-1000-s21/document/installation-guide
• Documentation Literaturewww.bimstore.co/products/civic-ec-db-1000-s21/document/product-literature
• Documentation Maintenancewww.bimstore.co/products/civic-ec-db-1000-s21/document/maintenance-information
• Documentation Technicalwww.bimstore.co/products/civic-ec-db-1000-s21/document/technical-data-sheet
• Drain Connection Diameter8 mm
• Duct Connection Diameter315 mm
• Duration UnitYears
• d W5 mm
• Expected Life0
• Extract Air FilterG4x2
• Featuresn/a
• Finishn/a
• Graden/a
• Grid MaterialGrid Cross
• H542 mm
• H1559 mm
• H2219 mm
• Hb229 mm
• Hc125 mm
• Heat Exchanger Typecounter-flow
• Heatrecoveryefficiency Percentage83..93
• Ht188 mm
• Ifc Export AsIfcEnergyConversionDeviceType
• Ifc Export TypeIfcUnitaryEquipmentTypeEnum.AIRCONDITIONINGUNIT
• L1202 mm
• L11242 mm
• Load ClassificationHVAC
• Maintenance Zone Height600 mm
• Maintenance Zone MaterialMaintenance Zone
• ManufacturerBlauberg
• Manufacturer NameBlauberg UK
• Materialn/a
• Maximum Air Flow1000 m³/h
• Maximum Unit Current With Electric Heater2 A
• Maximum Unit Current Without Electric Heater2 A
• Maximum Unit Power Without Electric Heater260 W
• ModelCIVIC EC DB 1000 S21
• Model NumberCivic EC DB10002
• Model ReferenceCIVIC EC DB 1000 S21
• NBS DescriptionSupply air handling units
• NBS Object NameBlauberg UK - Air Handling Units
• NBS Office Master Tagn/a
• NBS Reference90-45-15/310
• Nominal Depth0 mm
• Nominal Height0 mm
• Nominal Length0 mm
• Number Of Poles3
• of H120 mm
• of Left628 mm
• of Left Center828 mm
• of Right470 mm
• of Right Center670 mm
• of W400 mm
• os Back408 mm
• os H168 mm
• os W658 mm
• Power260 W
• Power Factor1
• Preheat Power0 W
• Production Year2021
• Referenced Standardn/a
• Reheater Power0 W
• Replacement Costn/a
• RP Mmin 12070
• SEC ClassA+
• Shapen/a
• Sizen/a
• Sound Pressure Levelat 1m DBA35
• Sound Pressure Levelat 3m DBA25
• Spare Partsn/a
• Supply Air FilterG4x2 + (option: F7 x 2)
• Transported Air Temperature Degrees C–25 …+40
• Type CommentsSingle-room ventilation unit CIVIC EC DB 1000 S21
• Type NameSingle-room ventilation unit CIVIC EC DB 1000 S21
• URLwww.blauberg.co.uk/
• Voltage400 V
• W2327 mm
• W1194 mm
• W21764 mm
• Warranty Descriptionn/a
• Warranty Duration Labor0
• Warranty Duration Parts0
• Warranty Duration UnitYears
• Warranty Guarantor Laborn/a
• Warranty Guarantor Partstechnicalsupport@blauberg.co.uk
• Weight267 kg
• W Left Part603 mm
• W Right Part423 mm
