Safety Relief (SRV) FIG 707 - Unset

Download Add to collection

Description

SAFETY RELIEF VALVE

Object Data

1 Revision

Last Updated

17/04/2019

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Product Data Sheet

Object metadata

Object

Parameter Type

_Authorwww.alusservices.co.uk
_Bim Spec Guid0
_BS Bible Version15
_Created Bywww.alusservices.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
A129 mm
A218 mm
Accessibility PerformanceN/A
Adjustment Screw MaterialBronze
AirYes
ApplicationPressure relief valves
ApprovalWRAS
Assembly CodeD30
Asset TypeFixed
B263 mm
Ball MaterialStainless Steel
BIM Object NameBOSS_PipeAccessories_SRV_BOSS_707_Unset
BodyBronze
Bot AF30 mm
Bush MaterialPTFE
Classification NameUniclass2015
Classification ValuePr_65_54_95_75
Code PerformanceN/A
ColorBronze
Connection1/2" Screwed BSPP Female x Female
ConstituentsN/A
Created Byenquiries@bssgroup.com
Created On43546.375
D427 mm
DescriptionSAFETY RELIEF VALVE
Disc MaterialStainless Steel / EPDM
Documentation CertificatesN/A
Documentation Installation GuideN/A
Documentation LiteratureN/A
Documentation MaintenanceN/A
Documentation TechnicalN/A
Dome MaterialBronze
Duration Unityears
EAN CodeN/A
Expected Life0
FeaturesSuitable for duty on air and water
FinishBronze
Gas CombustibleNo
Gas CorrosiveNo
Gas InertNo
Gas OxygenNo
GPID CodeN/A
GradeN/A
H193 mm
H339 mm
H426 mm
H528 mm
H78 mm
Handle Depth5 mm
Handle Thick2 mm
HH172 mm
Ifc Export AsIfcValveType.PRESSURERELIEF
Ifc Export TypeIfcValve
K Coefficient0
K Coefficient TableGlobe Valve Threaded
Keynote15700
Lever MaterialBronze
Lockring Ring MaterialBronze
Logo Depth13 mm
Loss MethodNot Defined
ManufacturerBSS BOSS Products
Manufacturer NameBSS BOSS Products
MaterialBronze Body
Maximum Working Pressure0.35-1.0 Bar
Maximum Working Temperature95°C
ModelBOSS 707 SAFETY RELIEF VALVE UNSET PRESSURE RANGE 0.35-1.0 Bar DN15
Model Number66520931
Model ReferenceBOSS 707 SAFETY RELIEF VALVE UNSET PRESSURE RANGE 0.35-1.0 Bar DN15
NBS DescriptionSafety valves
NBS Object NameBSS BOSS Products -Safety valves
NBS Office Master TagN/A
NBS Reference90-10-90/376
Nominal Depth35 mm
Nominal Dia20 mm
Nominal Height132 mm
Nominal Length63 mm
Nominal Width63 mm
OilNo
Pinning Screw MaterialSteel
Pressure DropN/A
Production Year2019
R28 mm
R318 mm
R518 mm
Referenced StandardBS EN ISO 4126 Part 1
Replacement CostN/A
S Depth15 mm
Seat MaterialBronze
ShapeCylindrical
SizeDN15
Spare PartsBOSS Technical Team Tel 0116 245 5940
Spindle MaterialStainless Steel
Spring Cap MaterialStainless Steel
Spring MaterialChrome Alloy
st4 mm
SteamNo
THB24 mm
THL31 mm
THP16 mm
Thread Clearance8 mm
TSS16 mm
Type CommentsBOSS 707 SAFETY RELIEF VALVE UNSET PRESSURE RANGE 0.35-1.0 Bar DN15
Type NameBOSS 707 SAFETY RELIEF VALVE UNSET PRESSURE RANGE 0.35-1.0 Bar DN15
URLwww.bssindustrial.co.uk/products/valves-and-filtration
Valve TypeSafety Relief Valve
W129 mm
Warranty DescriptionN/A
Warranty Duration Labor0
Warranty Duration Parts1
Warranty Duration Unityears
Warranty Guarantor Laborenquiries@bssgroup.com
Warranty Guarantor Partsenquiries@bssgroup.com
WaterYes
Weight0.718

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
