Angle Bracket AB505035

Object metadata

• _AuthorCL
• _Authorized ByRW
• _Bim Spec Guid0
• _BS Bible Version16
• _Created Bywww.bimstore.co
• _Current Revision1
• _Distributed Bywww.bimstore.co
• _Object User Guidewww.bimstore.co/products/angle-bracket-ab505035/document/object-user-guide
• Accessibility Performancen/a
• Assembly CodeB10
• Asset TypeFixed
• BIM Object NameExpamet_GalvanizedSteelBrackets_AngleBracket_AB505035_2D
• Classification NameUniclass_2015
• Classification ValuePr_20_85_09_33
• Code PerformanceBS EN 10346:2015, DX51D + Z275
• ColorSteel
• Constituentsn/a
• Created Byinfo@birtleygroup.co.uk
• Created On2019
• DescriptionUsed as a safe economical method of connecting joists to perlins.
• Documentation Certificateswww.expamet.co.uk
• Documentation Installation Guidewww.expamet.co.uk
• Documentation Literaturewww.expamet.co.uk
• Documentation Maintenancewww.expamet.co.uk
• Documentation Technicalwww.expamet.co.uk
• Duration UnitYears
• Expected Life0
• Features2mm Thick Hot Dip Galvanized
• FinishHot Dip Galvanized Mild Steel
• Graden/a
• Ifc Export AsIfcMember
• Ifc Export TypeIfcMemberTypeEnum.PLATE
• KeynoteG10/130
• ManufacturerExpamet
• Manufacturer NameExpamet
• MaterialHot Dip Galvanized Mild Steel
• ModelAB505035 Angle Bracket
• Model NumberAngle Bracket
• Model ReferenceAB505035 Angle Bracket
• NBS DescriptionGalvanized steel brackets
• NBS Object NameExpamet; Galvanized steel brackets
• NBS Office Master Tagn/a
• NBS Reference45-70-05/370
• Nominal Depth2 mm
• Nominal Height50 mm
• Nominal Length35 mm
• Production Year2019
• Referenced StandardBS EN 10346:2015, DX51D + Z275
• Replacement Costn/a
• ShapeL
• Size40mm x 40mm
• Spare Partsn/a
• Thickness2 mm
• Type CommentsAngle Bracket
• Type NameAB505035 Angle Bracket
• URLwww.expamet.co.uk/
• Warranty Descriptionn/a
• Warranty Duration Labor0
• Warranty Duration Parts0
• Warranty Duration UnitYears
• Warranty Guarantor Laborinfo@birtleygroup.co.uk
• Warranty Guarantor Partsinfo@birtleygroup.co.uk
