Type C Cavitrays

Type C cavitrays provide a harmonising yet independent DPC tray for all lintel openings. Manufactured from solid DPC, Type C cavitrays are pre-shaped to suit customer’s specific construction needs. Being pre-shaped means the installer establishes exactly what is being built into the cavity wall, whilst eliminating the dangers of distortion and misplacement.

This download is a 2D detail component created by bimstore.co.uk for Cavity Trays.

This component is created in Revit 2014 and is in line with 2015 industry standards.
