Everdry Stepped Cavity Trays for Stonework - Lead Attached
Description
BBA-approved stepped leaded cavity tray system for multi cavity options in stone wall construction of 150mm coursing heights.
Everdry preformed cavity trays are a range of DPC products for installation at the abutment of a pitched roof with a cavity wall to prevent water penetration. All Everdry cavity tray components are designed to comply fully with the requirements set out in Building Regulations, British Standards and the NHBC.
Uses:
- At the abutment of a pitched roof with a cavity wall
- On external walls – not exceeding 150mm thickness – built from natural or reconstituted stone with regular course heights, including mortar of approx. 150mm
- On roof pitches of 15 degrees and above
- Clear cavity widths of between 50mm-125mm
| Description | Length | 50-74mm (W) | 75-99mm (W) | 100-125mm (W) |
Intermediate tray RH | Varies | 8101 | 8103 | 8105 |
Intermediate tray LH | Varies | 8102 | 8104 | 8106 |
Intermediate tray RH | 450mm | 8131 | 8133 | 8135 |
Intermediate tray LH | 450mm | 8132 | 8134 | 8136 |
Corner starter tray RH* | 550mm | 7141 | 7143 | 7145 |
Corner starter tray LH* | 550mm | 7142 | 7144 | 7146 |
Ridge tray | 450mm | 8161 | 8162 | 8163 |
Click here to visit the product page on Timloc
