Fully airtight and high-level acoustic performance plastic access panels for providing access to concealed services and connections behind dry lined walls, ducts, ceilings, and cupboard units.
An economical solution for providing access to concealed services and helping to meet the requirements of:
Features a unique integral airtight seal design that reduces the air permeability to 0.00/h.m +50pa, under positive pressure test conditions.
Uses:
Frame fitting size | Clear opening size | Overall panel and frame size | Door type | Product code |
115 x 165mm | 100 x 150mm | 135 x 185mm | Clip fit | AP110AT |
155 x 235mm | 140 x 220mm | 195 x 275mm | Clip fit | AP150AT |
205 x 205mm | 190 x 190mm | 245 x 245mm | Clip fit | AP200AT |
305 x 305mm | 290 x 290mm | 345 x 345mm | Clip fit | AP300AT |
470 x 470mm | 455 x 455mm | 510 x 510mm | Clip fit | AP450AT |
Click here to visit the product page on Timloc
Read more1 Revision
19/12/2024

Compliant
Compliant
Not Available
Not available.
There are no EPDs.
