Slimline - Lounge Plates

10.8k
0
- / 5
Rate this product

-

Compliant

BS1192:4

Compliant

BSB

Compliant

Object Data

1 Revision

Last Updated

10/07/2023

Download BIM

Add to collection

Available for:

Slimline offers a comprehensive range of accessories including sockets with outboard rocker switches, wide rocker switches, LED dimmers, USB charging sockets and data modules to meet the demands of all modern day domestic and commercial applications.

Up to 6 single modules can be installed, full range of TV & Data modules. Sockets have clear markings, backed out & captive terminals, recessed earth bar

Products in the Slimline range are guaranteed for 25 years (2 years for electronic products).

This download is for the Slimline - Lounge Plates Range and includes the following types;

SD1977 - 4 gang 13A socket & 6 data module spaces
SD1978 - 4 gang 13A socket, Male co-axial & Telephone secondary module plus blank module spaces

_AuthorIan Holmes
_Authorized ByKris Atkinson
_Bim Spec Guid0
_BS Bible Version14
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility Performancen/a
Assembly CodeD5020120
Asset TypeFixed
Back Box Depth40 mm
BIM Object NameElectricalFixtures_DetaElectrical_Slimline_LoungePlates
Classification NameUniclass2015
Classification ValuePr_75_51_17_50
Code Performancen/a
ColorWhite
Constituentsn/a
Created Bysales@detaelectrical.co.uk
Created On2017-04-27T00:00:00
Default Elevation1219 mm
Description4 gang 13A socket & 6 data module spaces
Documentation Certificatesn/a
Documentation Installation Guidespecifi.bimstore.co.uk/document/share/2157
Documentation Literaturespecifi.bimstore.co.uk/document/share/2157
Documentation Maintenancen/a
Documentation Technicalspecifi.bimstore.co.uk/document/share/2157
Duration UnitYears
Expected Life0
FeaturesUpto 6 single modules can be installed, full range of TV & Data modules. Sockets have clear markings, backed out & captive terminals, recessed earth bar
Finishn/a
Graden/a
Height207 mm
Ifc Export AsIfcJunctionBoxTypeEnum.POWER
Ifc Export TypeIfcJunctionBox
KeynoteV
ManufacturerDeta Electrical
Manufacturer NameDeta Electrical
MaterialUrea Formaldehyde
ModelSlimline - Lounge Plates
Model Numbersd1977
Model ReferenceSlimline - Lounge Plates
NBS DescriptionManual control switches
NBS Object NameDeta Electrical - Manual control switches
NBS Office Master Tagn/a
NBS Referencen/a
Nominal Depth7 mm
Nominal Height207 mm
Nominal Length267 mm
Production Year2017
Referenced StandardBS 1363:pt2
Replacement Costn/a
Shapelandscape
Size267mm x 207mm
Spare Partsn/a
Switch MaterialDetaElectrical_White
Thickness7 mm
Type CommentsLounge Plates - sd1977
Type NameLounge Plates - sd1977
Unit MaterialDetaElectrical_White
URLwww.detaelectrical.co.uk/
Warranty DescriptionProducts in the Slimline range are guaranteed for 25 years (2 years for electronic products).
Warranty Duration Laborn/a
Warranty Duration Parts25
Warranty Duration UnitYears
Warranty Guarantor Laborsales@detaelectrical.co.uk
Warranty Guarantor Partssales@detaelectrical.co.uk
Width267 mm
