The SD120T 4x4 self-drive work platform delivers an impressive working envelope and with the advantage of a telescopic upper boom, supreme accuracy when positioning the platform.

Hydraulic outriggers and 45% gradeability allow the SD120T 4x4 to be driven and levelled on uneven surfaces making it ideal for environments with rough or softer ground and its low overall weight means better fuel efficiency and lower transportation costs.

Niftylift's highly effective Bi-Energy system increases flexibility and maximises utilisation allowing the SD120T 4x4 to operate for longer and in a wider range of environments.

For more information regarding the SD120T 4x4 or any other self-drive work platform, including the SD170 4x4 and SD210 4x4x4, please contact us.



SD120T 4x4 Features

Weight Saving Design

Low cost transportation and better fuel economy on site

Bi-Energy Available

Optimising utilisation

Telescopic Upper Boom

Greater accuracy when positioning the platform

Fully Proportional Hydraulic Controls

Simple, reliable & easy to maintain


Hydraulic Outriggers

Quick and easy to set up



SD120T 4x4 Specifications

Working Height (A)

12.65m (42ft)

Working Outreach (C)

6.1m (20ft)

Platform Height (B)

10.65m (35ft)

Machine Width (F)

1.56m (5ft 1in)

Machine Height (D)

1.95m (6ft 5in)

Machine Length (J)

3.9m (12ft 10in)

Working Width (G)

3.2m (10ft 6in)

Travel Speed

5.8km/h (3.6mph)

Gradeability

45%

Gradeability

24°

Turning Radius

3.9m (12ft 10in)

Minimum Weight

2260kg (4980lbs)

Safe Working Load

200kg (440lbs)

Cage Width

1.1m (3ft 7in)

Cage Depth

0.65m (2ft 2in)

Power Options

Battery only
Petrol or Diesel Only
Bi-Energy (Engine & Battery)





Keywords: MEWP, Mobile Elevating Work Platform, Cherry Picker, Boom Lift, Work Platform, Aerial Work Platform
