Grohe - Solido Monobloc Concealed Cistern With Frame - 39377LS0

by GROHE

Download Add to collection

Description

1.13 m finished installation height; for against-the-wall installations; powder coated steel frame, self-supporting; quick adjustment, lockable; fixing material; 2 WC fixing bolts; fixing device for ceramic; distance of fixing bolts 180/230 mm; depth adjustable; inlet and outlet connecting set; flushing cistern GD 2, 6 - 3 l; factory set 6 l and 3 l; pneumatic discharge valve offering 2 modes of operation: dual flush or start/stop; water supply from left/right or back; low noise (group I acc. To German Noise Specification); Insulated against condensation; ½" water supply connection including integrated angle valve and push fit flexible hose union; no tools required for the installation of the inspection shaft incl. protection during construction phase; for vertical use; with fixing material; including acrylic cover; white; Skate Cosmopolitan flush plate, chrome.

Object Data

1 Revision

Last Updated

07/12/2021

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

_AuthorAM
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co
_Current Revision1
_Distributed Bywww.bimstore.co
_Object User Guidewww.bimstore.co/products/grohe-solido-monobloc-concealed-cistern-with-frame/document/object-user-guide
Accessibility Performancen/a
Assembly CodeD2010900
Asset Typen/a
BIM Object NameGrohe_PlumbingFixtures_ConcealedCisternWithFrame_SolidoMonobloc_39377LS0
Classification NameUniclass 2015
Classification ValuePr_40_20_93_89
CO2 Neutral ProductionGROHE is one of the first leading manufacturer within the sanitary industry having a CO2-neutral production.
Code Performancen/a
ColorMoon White
Constituentsn/a
Cradle To Cradle Certificationn/a
Created Byinfo-uk@grohe.com
Created On2021-11-26 T09:00:00
CW ConnectionYes
CWFU0
Default Elevation0 mm
Description1.13 m finished installation height; for against-the-wall installations; powder coated steel frame, self-supporting; quick adjustment, lockable; fixing material; 2 WC fixing bolts; fixing device for ceramic; distance of fixing bolts 180/230 mm; depth adjustable; inlet and outlet connecting set; flushing cistern GD 2, 6 - 3 l; factory set 6 l and 3 l; pneumatic discharge valve offering 2 modes of operation: dual flush or start/stop; water supply from left/right or back; low noise (group I acc. To German Noise Specification); Insulated against condensation; ½" water supply connection including integrated angle valve and push fit flexible hose union; no tools required for the installation of the inspection shaft incl. protection during construction phase; for vertical use; with fixing material; including acrylic cover; white; Skate Cosmopolitan flush plate, chrome.
Documentation Certificateswww.bimstore.co/products/grohe-solido-monobloc-concealed-cistern-with-frame/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/grohe-solido-monobloc-concealed-cistern-with-frame/document/installation-guide
Documentation Literaturewww.bimstore.co/products/grohe-solido-monobloc-concealed-cistern-with-frame/document/product-literature
Documentation Maintenancewww.bimstore.co/products/grohe-solido-monobloc-concealed-cistern-with-frame/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/grohe-solido-monobloc-concealed-cistern-with-frame/document/technical-data-sheet
Duration UnitYear
EF000007n/a
EF000008560 mm
EF0000401160 mm
EF000041EV021883
EF000049175 mm
EF000116n/a
EF000386175
EF001139n/a
EF001187n/a
EF001251n/a
EF001257n/a
EF002147n/a
EF002169Other
EF002978n/a
EF006009n/a
EF010237n/a
EF0108710
EF011715n/a
EF020259n/a
EF020261n/a
EF020295n/a
EF020698n/a
EF020699n/a
EF020700n/a
EF020701n/a
EF020712n/a
EF020713n/a
EF020714n/a
EF020715n/a
EF020716n/a
EF020717n/a
EF020718n/a
EF020719n/a
EF020819n/a
EF020820n/a
EF020821n/a
EF021199n/a
EF021200n/a
EF021313n/a
EF021317n/a
EF021319n/a
EF021451n/a
EF021607n/a
EF022411n/a
EF022822n/a
EF022823n/a
EF023159n/a
EF023617n/a
EF023618n/a
EF023623n/a
EF023624n/a
EF023789n/a
EF023790n/a
EF023791n/a
EF023815n/a
EF023826n/a
EF023827n/a
EF023829n/a
EF023830n/a
EF023831n/a
EF023832n/a
EF023833n/a
EF023835n/a
EF023836n/a
EF023870n/a
EF023892n/a
EF023893n/a
EF024127n/a
EF024897n/a
EFDE0046n/a
Expected Life0
Featuresn/a
Finishn/a
Full Recyclability Of PlasticAll plastic components are fully recycable
Graden/a
GROHE Social Committmentgreen.grohe.com/social_engagement
GROHE Sustainabilitygreen.grohe.com
HW ConnectionYes
HWFU0
Ifc Export AsIfcFlowTerminalType
Ifc Export TypeIfcSanitaryTerminalTypeEnum.CISTERN
KeynoteN13
ManufacturerGrohe
Manufacturer NameGrohe
Materialn/a
Model39377LS0
Model Number39377LS0
Model ReferenceSolido Monobloc Concealed Cistern with Frame
NBS DescriptionGrohe - WC cisterns
NBS Object NameWC cisterns
NBS Office Master Tagn/a
NBS Reference45-35-70/383
Nominal Depth175 mm
Nominal Height1160 mm
Nominal Length560 mm
Primary MaterialPowder Coated Steel, Moon White
Production Year2021
Product Number39377LS0
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Parts1: Threaded bolt (Order-nr. 4276400M); 2: WC inlet and outlet connecting set (Order-nr. 37311K00); 2.1: Basin fastening (Order-nr. 43511SH0); 2.2: Connector (Order-nr. 37119000); 3: PP-outlet bend Ø 90 mm (Order-nr. 42327000); 4: 4" outlet adaptor for Rapid SL (Order-nr. 42242000); 5: Support for outlet bend (Order-nr. 42243000); 6: Filling valve (Order-nr. 42583000); 6.1: Lever (Order-nr. 43734000); 6.1.1: Sealing washer (Order-nr. 4377000M); 6.2: Valve head (Order-nr. 43536000); 6.3: Membrane (Order-nr. 4375800M); 6.4: Screw cap (Order-nr. 43735000); 6.5: Valve FLOAT, 5 pcs.. (Order-nr. 4379100M); 6.6: Set of seals (Order-nr. 43722000)*; 7: Support device (Order-nr. 42246000); 8: Connecting hose (Order-nr. 42233000); 8.1: O-Ring (Order-nr. 0319100M); 9: Dual Flush discharge valve AV1 (Order-nr. 42320000); 9.1: Extension for overflow pipe (Order-nr. 42313000); 9.2: Pneumatic hose (Order-nr. 42319000); 9.3: Sealing washer (Order-nr. 42310000); 10: Valve seat for GD2 (Order-nr. 42315000); 11: Front wall brackets (Order-nr. 3855800M); 12: Top plate with push button (Order-nr. 42371000); 13: Fixing set (Order-nr. 4215800M); 14: Set of seals (Order-nr. 43722000)*; 15: Set for noise protection (Order-nr. 37131000)*; 16: 4.5 l adapter for GD2 (Order-nr. 42333000)*; 17: Flow restrictor (Order-nr. 42300000)* [* Optional accessories].
Sustainability Awardgreen.grohe.com/awards
Sustainability Reportgreen.grohe.com/reporting
Type CommentsSolido Monobloc Concealed Cistern with Frame
Type NameSolido Monobloc Concealed Cistern with Frame
URLwww.grohe.co.uk/en_gb/
Vent ConnectionNo
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYear
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com
Waste ConnectionNo
WFU0
