Grohe Plus Three - Hole Single - Level Bath Combination - 23845003

by GROHE

Download Add to collection

Description

Three hole installation
GROHE SilkMove 35 mm ceramic cartridge with temperature limiter
GROHE StarLight chrome
single lever mixer operating element
diverter bath/shower without spout
Euphoria Cube hand shower 7.6 l/min metal shower hose
2000 mm flexible connection hoses connection for shower hose
protected against backflow

Object Data

-

Last Updated

09/08/2019

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Maintenance Information

Technical Data Sheet

Object metadata

_AuthorJack Yellop
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co
_Current Revision1
_Distributed Bywww.bimstore.co
Accessibility Performancen/a
Assembly CodeC1030
Asset TypeFixed
BIM Object NameGrohe_PlumbingFixtures_PlusThree-HoleSingle-LeverBathCombination_23845003
Classification NameUniclass2015
Classification ValuePr_40_20_87_96
Code Performancen/a
ColorSilver
Constituentsn/a
Created Byinfo-uk@grohe.com
Created On2019-04-29T09:00:00
CW ConnectionYes
CWFU4.5
Default Elevation0 mm
Descriptionthree hole installation, GROHE SilkMove 35 mm ceramic cartridge, with temperature limiter, GROHE StarLight chrome finish, consisting of: single lever mixer operating element, diverter bath/shower without spout, Euphoria Cube hand shower 7.6 l/min, metal shower hose 2000 mm, flexible connection hoses, connection for shower hose, protected against backflow, can be used with 29 037 001 for combination with 28 990 / 28 991 min. recommended pressure 1.0 bar
Documentation Certificatesn/a
Documentation Installation Guiden/a
Documentation Literaturen/a
Documentation Maintenancen/a
Documentation Technicaln/a
Duration UnitYears
Expected Life0
Featuresthree hole installation, GROHE SilkMove 35 mm ceramic cartridge, with temperature limiter, GROHE StarLight chrome finish, consisting of: single lever mixer operating element, diverter bath/shower without spout, Euphoria Cube hand shower 7.6 l/min, metal shower hose 2000 mm, flexible connection hoses, connection for shower hose, protected against backflow, can be used with 29 037 001 for combination with 28 990 / 28 991 min. recommended pressure 1.0 bar
FinishChrome
Graden/a
HW ConnectionYes
HWFU4.5
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
KeynoteN13
ManufacturerGrohe
Manufacturer NameGrohe
MaterialChrome
ModelPlus Three-hole single-lever bath combination
Model Number23845003
Model ReferencePlus Three-hole single-lever bath combination
NBS DescriptionWater supply fittings for wash basins and troughs
NBS Object NameGrohe - Water supply fittings for wash basins and troughs
NBS Office Master Tagn/a
NBS Reference45-35-70/371
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Primary FinishGrohe- Chrome
Production Year2019
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsn/a
Type Comments23845003
Type NamePlus Three-hole single-lever bath combination
URLwww.grohe.co.uk/en_gb/
Vent ConnectionNo
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborn/a
Warranty Guarantor Partsinfo-uk@grohe.com
Waste ConnectionNo
