Grohe Grohtherm 800 Cosmopolitan Thermostatic shower mixer 1/2" FR, NF/C3 - 34771000

Object metadata

• _AuthorAM
• _Authorized Bybimstore
• _Bim Spec Guid0
• _BS Bible Version16
• _Created Bywww.bimstore.co
• _Current Revision1
• _Distributed Bywww.bimstore.co
• Accessibility Performancen/a
• Assembly CodeC1030
• Asset TypeFixed
• BIM Object NameGrohe_PlumbingFixtures_ThermostaticShowerMixer_Grohtherm800Cosmopolitan-34771000
• Classification NameUniclass2015
• Classification ValuePr_40_20_87_81
• Code Performancen/a
• ColorChrome
• Constituentsn/a
• Created Byinfo-uk@grohe.com
• Created On2020-04-015 T09:00:00
• CW ConnectionYes
• CWFU0
• Default Elevation1016.00 mm
• Depth70.00 mm
• DescriptionWall mounted; GROHE StarLight chrome finish; GROHE MetalGrip ergonomically shaped metal handles; GROHE SafeStop safety button at 38°C; GROHE SafeStop Plus integrated temperature limiter at max 50°C; GROHE TurboStat C3 compact cartridge with wax thermoelement; Integrated mixed water shut off; Volume handle with GROHE EcoButton (economy button with individually adjustable economy stop); Ceramic headpart 1/2", 180°; Shower bottom outlet 1/2"; Built-in non-return valves; Dirt strainers; Protected against backflow; S-unions; Metal escutcheon; GROHE EcoJoy technology for less water and perfect flow.
• Documentation Certificatesn/a
• Documentation Installation Guiden/a
• Documentation Literaturen/a
• Documentation Maintenancen/a
• Documentation Technicaln/a
• Duration UnitYear
• Expected Life0
• FeaturesWall mounted; GROHE StarLight chrome finish; GROHE MetalGrip ergonomically shaped metal handles; GROHE SafeStop safety button at 38°C; GROHE SafeStop Plus integrated temperature limiter at max 50°C; GROHE TurboStat C3 compact cartridge with wax thermoelement; Integrated mixed water shut off; Volume handle with GROHE EcoButton (economy button with individually adjustable economy stop); Ceramic headpart 1/2", 180°; Shower bottom outlet 1/2"; Built-in non-return valves; Dirt strainers; Protected against backflow; S-unions; Metal escutcheon; GROHE EcoJoy technology for less water and perfect flow.
• FinishChrome
• Graden/a
• Height96.50 mm
• HW ConnectionYes
• HWFU0
• Ifc Export AsIfcPipeFitting
• Ifc Export TypeIfcPipeFittingType
• KeynoteN13
• Length298.00 mm
• ManufacturerGrohe
• Manufacturer NameGrohe
• MaterialChrome
• Mixer MaterialGrohe - Metal - Chrome
• ModelGrohtherm 800 Cosmopolitan
• Model Number34771000
• Model ReferenceGrohtherm 800 Cosmopolitan
• NBS DescriptionShower mixers
• NBS Object NameGrohe - Shower mixers
• NBS Office Master Tagn/a
• NBS Reference45-35-70/335
• Nominal Depth70.00 mm
• Nominal Height96.50 mm
• Nominal Length298.00 mm
• Production Year2020
• Referenced Standardn/a
• Replacement Costn/a
• Shapen/a
• Sizen/a
• Spare PartsTemperature control handle (47985000); Cover cap (6458500M); Fitting ring (47743000); Thermostatic compact cartridge 1/2" (47885000); Ceramic headpart 1/2" (45346000); O-ring Ø 18.2 x Ø 1.7 (0392400M); Metal handle 1/2" (47984000); Cover cap (6458500M); Non-return valve (47189000); Dirt strainer (0726400M); Non-return valve (08565000); O-ring ø 17 x ø 2 (0305500M); S-union (12662000); Non-return valve (47886000); Extension 3/4", 20mm (0713000M*); Socket spanner (19332000*); GROHE TurboStat cartridge 1/2" (47175000*); Special spanner (19377000*). *Optional Accessories.
• Type Comments34771000
• Type NameGrohtherm 800 Cosmopolitan
• URLwww.grohe.co.uk/en_gb/
• Vent ConnectionNo
• Warranty Descriptionn/a
• Warranty Duration Labor0
• Warranty Duration Parts0
• Warranty Duration UnitYear
• Warranty Guarantor Laborn/a
• Warranty Guarantor Partsinfo-uk@grohe.com
• Waste ConnectionNo
