EUROSMART COSMOPOLITAN Single-lever bath/shower mixer 1/2″ (32833000)

by GROHE

Download Add to collection

Description

wall mounted
metal lever
GROHE SilkMove 46 mm ceramic
cartridge with Eco-Override-Stop
GROHE StarLight chrome finish
adjustable flow rate limiter
adjustable minimum flow rate approx. 2.5 l/min
automatic diverter: bath/shower
mousseur
integrated non-return valve in the shower outlet 1/2"
S-unions
protected against backflow
optional temperature limiter ref. no. 08 791
Qualitel E1/E3C2A2U3 applied for

Object Data

2 Revision

Last Updated

13/05/2021

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Technical Data Sheet

Product Data Sheet

Object metadata

_AuthorRL
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co
_Current Revision1
_Distributed Bywww.bimstore.co
_Object User Guidewww.bimstore.co/products/grohe-eurosmart-cosmopolitan-single-lever-bath-mixer-32833000/document/object-user-guide
Accessibility Performancen/a
ADA CompliantNo
Assembly CodeD2010700
Asset Typen/a
BIM Object NameGrohe_PlumbingFixture_EurosmartCosmopolitan_SingleLeverBathShowerMixer_32833000
Classification NameUniclass 2015
Classification ValuePr_40_20_87_78
Code Performancen/a
Cold Water Connection Diameter10 mm
ColorChrome
Constituentsn/a
Contact Groheinfo-uk@grohe.com
Created Byinfo-uk@grohe.com
Created On2020-11-01T09:00:00
CWFU4.5
Default Elevation0 mm
DescriptionYour bathroom look will be enhanced by the chic wall-mounted GROHE Eurosmart mixer for the bathtub – and all without busting your budget. Operation is via the tactile solid metal lever while the automatic diverter lets you switch easily between bath and shower flow. The GROHE SilkMove ceramic cartridge offers smooth and precise volume and temperature control for the life of the tap. And, to help you save water, the Eco-Override-Stop function offers subtle resistance when you lift the lever beyond the most efficient water-saving flow rate. Finished in hardwearing GROHE StarLight chrome this mixer will sparkle for years to come.
Documentation Certificateswww.bimstore.co/products/grohe-eurosmart-cosmopolitan-single-lever-bath-mixer-32833000/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/grohe-eurosmart-cosmopolitan-single-lever-bath-mixer-32833000/document/installation-guide
Documentation Literaturewww.bimstore.co/products/grohe-eurosmart-cosmopolitan-single-lever-bath-mixer-32833000/document/product-literature
Documentation Maintenancewww.bimstore.co/products/grohe-eurosmart-cosmopolitan-single-lever-bath-mixer-32833000/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/grohe-eurosmart-cosmopolitan-single-lever-bath-mixer-32833000/document/technical-data-sheet
Duration UnitYears
EcojoyNo
Expected Life0
FeaturesYour bathroom look will be enhanced by the chic wall-mounted GROHE Eurosmart mixer for the bathtub – and all without busting your budget. Operation is via the tactile solid metal lever while the automatic diverter lets you switch easily between bath and shower flow. The GROHE SilkMove ceramic cartridge offers smooth and precise volume and temperature control for the life of the tap. And, to help you save water, the Eco-Override-Stop function offers subtle resistance when you lift the lever beyond the most efficient water-saving flow rate. Finished in hardwearing GROHE StarLight chrome this mixer will sparkle for years to come.
Finishn/a
Graden/a
Hot Water Connection Diameter10 mm
HWFU4.5
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
Industry Standardsn/a
KeynoteN13
LEED Creditn/a
Low Emitting MaterialNo
ManufacturerGrohe
Manufacturer NameGrohe
Masterformat Number01 52 19
Masterformat TitleSanitary Facilities
Materialn/a
ModelEurosmart Cosmopolitan - Single-lever bath/shower mixer 1/2″
Model Number32833000
Model ReferenceEurosmart Cosmopolitan - Single-lever bath/shower mixer 1/2″
NBS DescriptionShower mixers
NBS Object NameGrohe - Shower mixers
NBS Office Master Tagn/a
NBS Reference45-35-70/335
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Percentage Of Recycled Contentn/a
Primary MaterialSteel, Chrome Plated
Product Documentation Linkwww.grohe.co.uk/en_gb/eurosmart-cosmopolitan-single-lever-bath-shower-mixer-1-2-32833000.html
Production Year2020
Product Page URLwww.grohe.co.uk/en_gb/eurosmart-cosmopolitan-single-lever-bath-shower-mixer-1-2-32833000.html
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsn/a
Type Comments32833000
Type NameEurosmart Cosmopolitan - Single-lever bath/shower mixer 1/2″
URLwww.grohe.co.uk/en_gb/
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
