EUROSMART COSMOPOLITAN E Infra-red electronic basin mixer with mixing device and adjustable temperature limiter (36315000)

3.1k
0
- / 5
Rate this product

-

Compliant

BS1192:4

Compliant

BSB

Compliant

Object Data

1 Revision

Last Updated

01/09/2016

Download BIM

Add to collection

Available for:

with infrared sensor for bi-directional communication for monitoring, configuration and servicing with transformer 100-230 V AC, 50-60 Hz, 6 V DClaminar flow straightener 9 l/min.chrome escutcheonchrome spoutprojection 170 mm7 pre-set programsauto flushthermal disinfectioncleaning modeadditional functions and precise settings by remote control 36 407set for final installation for concealed fitting box36 339 000CE approvednoise classification 1 in accordance with DIN4109

This download is a face based plumbing fixture component created by bimstore.co.uk for Grohe.

This component is created in Revit 2014 for use in MEP systems and is in line with 2015 industry standards.

_BIMspec_GUID0
_created byConnor Laing
_created dateAugust 2016
_current revision1
_distributed bywww.bimstore.co.uk
ADA CompliantYes
Assembly CodeC1030220
Asset TypeFixed
Classification NameUniclass 2015
Classification ValuePr_40_20_87_08
Cold Water Connection Diameter10 mm
Cold Water Radius5 mm
ColorChrome
Contact GroheGROHE Limited, World Business Centre 2, Newall Road, London Heathrow Airport, Hounslow, Middlesex, TW6 2SF - Tel: +44 (0) 871 200 3414 - Fax: +44 (0) 871 200 3415 - EMail: info-uk@grohe.com
Created Byinfo-uk@grohe.com
Created OnAugust 2016
CW ConnectionYes
CWFU4.5
Default Elevation600 mm
DescriptionWith infrared sensor for bi-directional communication for monitoring, configuration and servicing with transformer 100-230 V AC, 50-60 Hz, 6 V DC laminar flow straightener 9 l/min. chrome escutcheon chrome spout projection 170 mm 7 pre-set programs auto flush thermal disinfection cleaning mode additional functions and precise settings by remote control 36 407 set for final installation for concealed fitting box 36 339 000 CE approved noise classification 1 in accordance with DIN4109
Duration UnitYears
EcojoyNo
Expected Life0
Faucet MaterialGrohe-Chrome
FinishChrome
Handle Spacing200 mm
Height60 mm
Hot Water Connection Diameter10 mm
Hot Water Radius5 mm
HW ConnectionYes
HWFU4.5
Industry StandardsN/A
KeynoteN13
Length193 mm
Low Emitting MaterialYes
ManufacturerGrohe AG
Mixed Pipe Constraint80 mm
Mixed Pipe Length145 mm
ModelEurosmart Cosmopolitan E Infra-red Basin mixer - 36315000
Model Number13276002
NameEurosmart Cosmopolitan E Infra-red Basin mixer - 36315000
NBS DescriptionWater supply fittings for wash basins and troughs;
NBS Object NameWater supply fittings for wash basins and troughs;
NBS Reference45-35-70/371
Percentage of Recycled Content0
Product Page URLpro.grohe.com/uk/5577/bathroom/tap-mixer/eurosmart-cosmopolitan/product-details/?product=36315-G307&color=000&material=36315000
Spare Parts Listpro.grohe.com/uk/5577/bathroom/tap-mixer/eurosmart-cosmopolitan/product-details/?product=36315-G307&color=000&material=36315000
Tag Number0
Type CommentsEurosmart Cosmopolitan E Infra-red electronic basin mixer with mixing device and adjustable temperature limiter
Type NameEurosmart Cosmopolitan E Infra-red Basin mixer - 36315000
URLwww.grohe.com
Vent ConnectionNo
Warranty InfomationN/A
Warranty Duration UnitYears
Waste ConnectionNo
WFU0
Width60 mm
