Grohe Euphoria System 260 - 26708000

Object metadata

• _AuthorJY
• _Authorized Bybimstore
• _Bim Spec Guid0
• _BS Bible Version16
• _Created Bywww.bimstore.co
• _Current Revision1
• _Distributed Bywww.bimstore.co
• _Object User Guiden/a
• Accessibility Performancen/a
• Assembly CodeD2010
• Asset TypeFixed
• BIM Object NameGrohe_PlumbingFixtures_EuphoriaSystem260_26708000
• Classification NameUniclass2015
• Classification ValuePr_40_20_87_75
• Code Performancen/a
• ColorSilver
• Constituentsn/a
• Created Byinfo-uk@grohe.com
• Created On2019-09-24T09:00:00
• Default Elevation1219 mm
• DescriptionEuphoria System 260 Shower system with bath thermostat for wall mounting consisting of: horizontal swivable 450 mm shower arm exposed thermostat with Aquadimmer function allows change between: head shower Euphoria 260 (26 457) 3 spray patterns: Rain, SmartRain, Jet with ball joint, rotation angle ± 15° bath inlet separate diverter for hand shower hand shower Euphoria 110 Massage (27 239) 3 spray patterns: Rain, SmartRain, Massage adjustable in height with gliding element Silverflex shower hose 1750 mm (28 388) without connection unions GROHE EcoJoy 9.5 l/min flow limiter GROHE TurboStat compact cartridge with wax thermoelement GROHE SafeStop safety button at 38°C GROHE SafeStop Plus optional temperature limiter at 43°C included GROHE DreamSpray perfect spray pattern GROHE StarLight chrome finish GROHE SprayDimmer (stepless flow rate reduction) SpeedClean anti-lime system Inner WaterGuide for a longer life Twistfree to prevent hose from twisting suitable for instantaneous heaters from 18 kW/h minimum flow rate 7 l/min min. recommended pressure 1.0 bar
• Documentation Certificateswww.grohe.co.uk/en_gb/
• Documentation Installation Guidewww.grohe.co.uk/en_gb/
• Documentation Literaturewww.grohe.co.uk/en_gb/
• Documentation Maintenancewww.grohe.co.uk/en_gb/
• Documentation Technicalwww.grohe.co.uk/en_gb/
• Duration UnitYears
• Expected Life0
• FeaturesEuphoria System 260 Shower system with bath thermostat for wall mounting consisting of: horizontal swivable 450 mm shower arm exposed thermostat with Aquadimmer function allows change between: head shower Euphoria 260 (26 457) 3 spray patterns: Rain, SmartRain, Jet with ball joint, rotation angle ± 15° bath inlet separate diverter for hand shower hand shower Euphoria 110 Massage (27 239) 3 spray patterns: Rain, SmartRain, Massage adjustable in height with gliding element Silverflex shower hose 1750 mm (28 388) without connection unions GROHE EcoJoy 9.5 l/min flow limiter GROHE TurboStat compact cartridge with wax thermoelement GROHE SafeStop safety button at 38°C GROHE SafeStop Plus optional temperature limiter at 43°C included GROHE DreamSpray perfect spray pattern GROHE StarLight chrome finish GROHE SprayDimmer (stepless flow rate reduction) SpeedClean anti-lime system Inner WaterGuide for a longer life Twistfree to prevent hose from twisting suitable for instantaneous heaters from 18 kW/h minimum flow rate 7 l/min min. recommended pressure 1.0 bar
• FinishChrome
• Graden/a
• Ifc Export AsIfcPipeFitting
• Ifc Export TypeIfcPipeFittingType
• KeynoteN13
• ManufacturerGrohe
• Manufacturer NameGrohe
• MaterialChrome
• ModelEuphoria System 260
• Model Number26708000
• Model ReferenceEuphoria System 260
• NBS DescriptionShower fittings package
• NBS Object NameGrohe - Shower fittings package
• NBS Office Master Tagn/a
• NBS Reference45-35-70/330
• Nominal Depth0 mm
• Nominal Height0 mm
• Nominal Length0 mm
• Production Year2019
• Referenced Standardn/a
• Replacement Costn/a
• Shapen/a
• Sizen/a
• Spare Partsn/a
• Type Comments26708000
• Type NameEuphoria System 260
• URLwww.grohe.co.uk/en_gb/
• Warranty Descriptionn/a
• Warranty Duration Labor0
• Warranty Duration Parts0
• Warranty Duration UnitYears
• Warranty Guarantor Laborn/a
• Warranty Guarantor Partsinfo-uk@grohe.com
