Full Recyclability Of PlasticAll plastic components are fully recycable
Graden/a
GROHE Social Committmentgreen.grohe.com/social_engagement
GROHE Sustainabilitygreen.grohe.com
HW ConnectionYes
HWFU4.5
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
KeynoteN13
ManufacturerGrohe
Manufacturer NameGrohe
Materialn/a
ModelGRANDERA Volume Control Trim
Model Number39933SH0
Model ReferenceIGNIA Shower Toilet
NBS DescriptionShower Toilet
NBS Noten/a
NBS Object NameGrohe - Shower Toilet
NBS Office Master Tagn/a
NBS Reference45-35-70/345
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
PQ Diagram Linkn/a
Primary MaterialGrohe_WhitePlastic
Product DescriptionGROHE HygieneClean: with antibacterial glazing HyperClean non-stick coating AquaCeramic
GROHE Power Flush: rimless siphon-jet WC with GROHE Double Vortex
rimless toilet bowl
automatic flush for seated users
antibacterial material spray arms (SIAA Kohkin Japanese standard compliant)
2 dedicated manual spray arms (1 for rear spray, 1 for lady spray)
separate water way for lady spray
oscillating spray (automatic forward and reverse motion of the spray)
pulsating spray for massage
automatic pre- and post-rinsing of spray nozzle with fresh water
integrated instant heater provides unlimited warm water
adjustable water temperature
exchangeable spray head
nozzle guard
designed spray angle for rear spray and lady spray
Additional functions:
warm air dryer with adjustable temperature
soft close ABS WC seat (SIAA Kohkin Japanese standard compliant)
adjustable seat temperature
Eco mode for reducing power consumption
seat control panel operation
unlimited manual flushing if power outage occurred
active carbon filter for odour absorption
automatic seat heat off for preventing low-temp burn
includes:
manual remote control with wall-mounted holder
1.0 m cable with system plug on device (with electrical leakage protection)
water valve with removable strainer
other specifications:
flush volume 5.0/3.5 l
pressure 0.08 – 0.75 MPa
rough in: 305 mm
nominal voltage 220 V AC
main frequency 50 Hz
type of protection IPX4
environment temperature 0 - 40 °C
