SKATE COSMOPOLITAN Flush Plate (38732KF0)

Download Add to collection

Description

Product Number - 38732KF0

EAN - 4005176784125

Colour - phantom black

PRODUCT MAIN FEATURES

for dual flush or start & stop actuation
for pneumatic drop valve AV1
for vertical and horizontal installation
GROHE Long-Life finish
GROHE Water Saving - Less water, perfect flow
for combination with Rapid SL 1.13 m with GD 2 cistern
for use with Rapid SLX please order shaft 66 791 000 (sold separately)

Product Page - https://www.grohe.co.uk/en_gb/skate-cosmopolitan-flush-plate-38732KF0.html

Object Data

1 Revision

Last Updated

22/09/2023

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Data Sheet

Object metadata

_AuthorAM 147
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/grohe-38732KF0/document/object-user-guide
Accessibility Performancen/a
Assembly CodeD2010
Asset TypeFixed
BIM Object NameGrohe_FlushPlate_SkateCosmopolitan_38732KF0
Classification NameUniclass2015
Classification ValuePr_75_50_46_68
CO2 Neutral ProductionGROHE is one of the first leading manufacturer within the sanitary industry having a CO2-neutral production.
Code Performancen/a
ColorMatt Black
Constituentsn/a
Cradle To Cradle Certificationn/a
Created Byinfo-uk@grohe.com
Created On2023-03-01T09:00:00
CW ConnectionNo
Default Elevation0.0 mm
DescriptionSKATE COSMOPOLITAN Flush Plate
Dimensions Document Linkcdn.cloud.grohe.com/dimdraw/1000/1200/1250/1258/1258705/1280/1258705.jpg
Documentation Certificateswww.bimstore.co/products/grohe-38732KF0/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/grohe-38732KF0/document/installation-guide
Documentation Literaturewww.bimstore.co/products/grohe-38732KF0/document/product-literature
Documentation Maintenancewww.bimstore.co/products/grohe-38732KF0/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/grohe-38732KF0/document/technical-data-sheet
Duration UnitYears
EcojoyNo
EF000007Black
EF000008156.0 mm
EF00004010.0 mm
EF001438197.0 mm
EF002147Two button
EF002169Plastic
EF006331FALSE
EF006949Pneumatic
EF010109FALSE
EF020827TRUE
EF020828TRUE
EF023751TRUE
EF023752TRUE
Expected Life0
Featuresn/a
Finishn/a
Full Recyclability Of PlasticAll plastic components are fully recyclable
Graden/a
GROHE Social Committmentgreen.grohe.com/social_engagement
GROHE Sustainabilitygreen.grohe.com
HW ConnectionNo
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
KeynoteN13
ManufacturerGrohe
Manufacturer NameGrohe
Materialn/a
ModelSKATE COSMOPOLITAN Flush Plate
Model Number38732KF0
Model ReferenceSKATE COSMOPOLITAN Flush Plate
NBS DescriptionPush-button flush controllers
NBS Noten/a
NBS Object NameGrohe - Push-button flush controllers
NBS Office Master Tagn/a
NBS Referencen/a
Nominal Depth0.0 mm
Nominal Height0.0 mm
Nominal Length0.0 mm
PQ Diagram Linkn/a
Primary MaterialGrohe_MattBlack
Product Descriptionfor dual flush or start & stop actuation for pneumatic discharge valve AV1 vertical and horizontal installation 156 x 197 mm made of ABS GROHE Long-Life Shine finish GROHE Water Saving - Less water, perfect flow for combination with Rapid SL and Uniset with GD 2 cistern for use with Rapid SLX please order shaft 66 791 000 (sold separately)
Production Year2023
Product Number38732KF0
Product Page URLwww.grohe.co.uk/en_gb/-38732KF0.html
Product Short TextSkate Cosmopolitan Flush Plate
Product TypeManual Actuation
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsinfo-uk@grohe.com
Sustainability Awardgreen.grohe.com/awards
Sustainability Reportgreen.grohe.com/reporting
TPI Document Linkcdn.cloud.grohe.com/tpi/2000/2000/2010/2013/2013141/original/2013141.pdf
Type CommentsSKATE COSMOPOLITAN Flush Plate
Type NameSKATE COSMOPOLITAN Flush Plate
URLwww.grohe.co.uk/
Vent ConnectionNo
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com
Waste ConnectionNo

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
