Flex Shower System (2738920C)

by GROHE

Download Add to collection

Description

Product Number - 2738920C

Colour - Chrome

PRODUCT MAIN FEATURES

horizontal 390 mm shower arm, adjustable before installation
change by diverter between hand shower, head shower or head shower Eco setting
head shower Tempesta Cosmopolitan 200 (27 541)
2 spray patterns (via diverter): Rain, SmartRain
with ball joint, rotation angle ± 15°
hand shower Tempesta 100 (28 578)
4 spray patterns: GROHE Rain O², Rain, Massage, Jet
adjustable in height with gliding element
distance between diverter and upper bracket: 620 mm
Relexaflex shower hose 1500 mm (28 151)
Relexaflex shower hose 1250 mm (28 150)
flexible installation: connection to faucet / wall union for water supply with 1/2" thread of the 1250 mm shower hose
minimum flow rate 7 l/min
GROHE DreamSpray perfect spray pattern
GROHE Long-Life finish
SpeedClean anti-limescale system
Inner WaterGuide for a longer life
ShockProof silicone ring prevents damages caused by shower falling

Product Page - https://www.grohe.co.uk/en_gb/-2738920C.html

Object Data

1 Revision

Last Updated

10/06/2024

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Data Sheet

Object metadata

_AuthorSM 183
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/grohe-2738920C/document/object-user-guide
Accessibility Performancen/a
Assembly CodeD2010
Asset TypeFixed
BIM Object NameGrohe_ShowerSystem_2738920C
Classification NameUniclass2015
Classification ValuePr_40_20_87_75
CO2 Neutral ProductionGROHE is one of the first leading manufacturer within the sanitary industry having a CO2-neutral production.
Code Performancen/a
ColorChrome
Constituentsn/a
Cradle To Cradle CertificationN/A
Created Byinfo-uk@grohe.com
Created On2024-05-28T09:00:00
CWFU4.5
Default Elevation0 mm
Descriptionconsisting of: horizontal 390 mm shower arm, adjustable before installation change by diverter between hand shower, head shower or head shower Eco setting head shower Tempesta Cosmopolitan 200 (27 541) 2 spray patterns (via diverter): Rain, SmartRain with ball joint, rotation angle ± 15° hand shower Tempesta 100 (28 578) 4 spray patterns: GROHE Rain O², Rain, Massage, Jet adjustable in height with gliding element distance between diverter and upper bracket: 620 mm Relexaflex shower hose 1500 mm (28 151) Relexaflex shower hose 1250 mm (28 150) flexible installation: connection to faucet / wall union for water supply with 1/2" thread of the 1250 mm shower hose minimum flow rate 7 l/min GROHE DreamSpray perfect spray pattern GROHE Long-Life finish SpeedClean anti-limescale system Inner WaterGuide for a longer life ShockProof silicone ring prevents damages caused by shower falling
Dimensions Document Linkcdn.cloud.grohe.com/dimdraw/2000/2000/2040/2040/2040355/1280/2040355.jpg
Documentation Certificateswww.bimstore.co/products/grohe-2738920C/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/grohe-2738920C/document/installation-guide
Documentation Literaturewww.bimstore.co/products/grohe-2738920C/document/product-literature
Documentation Maintenancewww.bimstore.co/products/grohe-2738920C/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/grohe-2738920C/document/technical-data-sheet
Duration UnitYears
EcojoyNo
Expected Life0
Featuresn/a
Finishn/a
Full Recyclability Of PlasticAll plastic components are fully recycable
Graden/a
GROHE Social Committmentgreen.grohe.com/social_engagement
GROHE Sustainabilitygreen.grohe.com
HWFU4.5
Ifc Export AsIfcFlowTerminalType
Ifc Export TypeIfcSanitaryTerminalTypeEnum.SHOWER
KeynoteN13
ManufacturerGrohe
Manufacturer NameGrohe
Materialn/a
Model2738920C
Model Number2738920C
Model ReferenceShower System (2738920C)
NBS DescriptionShower fittings package
NBS Noten/a
NBS Object NameGrohe - Shower fittings package
NBS Office Master Tagn/a
NBS Reference45-35-70/330
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
PQ Diagram Linkcdn.cloud.grohe.com/PQCharts/lores/2/273/original/2738920C-pqchart-en_GB.svg
Primary MaterialGrohe_Chrome
Product Descriptionconsisting of: horizontal 390 mm shower arm, adjustable before installation change by diverter between hand shower, head shower or head shower Eco setting head shower Tempesta Cosmopolitan 200 (27 541) 2 spray patterns (via diverter): Rain, SmartRain with ball joint, rotation angle ± 15° hand shower Tempesta 100 (28 578) 4 spray patterns: GROHE Rain O², Rain, Massage, Jet adjustable in height with gliding element distance between diverter and upper bracket: 620 mm Relexaflex shower hose 1500 mm (28 151) Relexaflex shower hose 1250 mm (28 150) flexible installation: connection to faucet / wall union for water supply with 1/2" thread of the 1250 mm shower hose minimum flow rate 7 l/min GROHE DreamSpray perfect spray pattern GROHE Long-Life finish SpeedClean anti-limescale system Inner WaterGuide for a longer life ShockProof silicone ring prevents damages caused by shower falling
Production Year2024
Product Number2738920C
Product Short TextFlex shower system with diverter for wall mounting
Product TypeShower System
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsinfo-uk@grohe.com
Sustainability Awardgreen.grohe.com/awards
Sustainability Reportgreen.grohe.com/reporting
Type CommentsShower System (2738920C)
Type NameShower System (2738920C)
URLwww.grohe.co.uk/
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborwww.grohe.co.uk
Warranty Guarantor Partswww.grohe.co.uk

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
