RAINSHOWER SMARTACTIVE 310 Shower System With Thermostat For Wall Mounting (22119KF0)

by GROHE

Download Add to collection

Description

Product Number - 22119KF0

EAN - 4005176782510

Colour - phantom black

PRODUCT MAIN FEATURES

Consisting of:
horizontal swivable 450 mm projection shower arm
exposed thermostatic showerwith Aquadimmer function
allows change between:
head shower Rainshower Mono 310
with ball joint
rotation angle ± 15°
hand shower Rainshower SmartActive 130 (22 127 KF0)
adjustable height via gliding element
including performance grip
Silverflex shower hose 1750 mm (28 388 000)
GROHE TurboStat compact cartridge with wax thermoelement
GROHE SafeStop safety button at 38°C ( calibration required )
GROHE SafeStop Plus optional temperature limiter at 43°C included
GROHE CoolTouch prevents scalding on hot surfaces
GROHE DreamSpray perfect spray pattern
GROHE SmartTip showering spray selection via push of a ring
GROHE Long-Life finish
GROHE Water Saving 9.5 l/min flow limiter
GROHE FastFixation upper bracket adjustable
SpeedClean anti-limescale system
suitable for instantaneous heaters from 18 kW/h
minimum flow rate 7 l/min.

Product Page - https://www.grohe.co.uk/en_gb/rainshower-smartactive-310-shower-system-with-thermostat-for-wall-mounting-22119KF0.html

Object Data

1 Revision

Last Updated

22/09/2023

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Data Sheet

Object metadata

_AuthorAM 147
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/grohe-22119KF0/document/object-user-guide
Accessibility Performancen/a
Assembly CodeD2010
Asset TypeFixed
BIM Object NameGrohe_ShowerSet_Rainshower_22119KF0
Classification NameUniclass2015
Classification ValuePr_40_20_87_75
CO2 Neutral ProductionGROHE is one of the first leading manufacturer within the sanitary industry having a CO2-neutral production.
Code Performancen/a
ColorMatt Black
Constituentsn/a
Cradle To Cradle Certificationn/a
Created Byinfo-uk@grohe.com
Created On2023-03-01T09:00:00
CW ConnectionYes
Default Elevation0.0 mm
DescriptionRAINSHOWER Shower Set
Dimensions Document Linkcdn.cloud.grohe.com/dimdraw/100000/100000/100000/100100/100150/100159/100159497/1280/100159497.jpg
Documentation Certificateswww.bimstore.co/products/grohe-22119KF0/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/grohe-22119KF0/document/installation-guide
Documentation Literaturewww.bimstore.co/products/grohe-22119KF0/document/product-literature
Documentation Maintenancewww.bimstore.co/products/grohe-22119KF0/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/grohe-22119KF0/document/technical-data-sheet
Duration UnitYears
EcojoyNo
EF000008317.0 mm
EF0000401118.0 mm
EF000049472.0 mm
EF000551310.0 mm
EF0006340.0 Pa
EF00170770 °C
EF002169Brass
EF002286External thread
EF002671Other
EF003454FALSE
EF003829FALSE
EF005084Wall
EF006009TRUE
EF006013FALSE
EF006974Thermostatic
EF020103FALSE
EF0207851/2 inch
EF021457FALSE
EF021607FALSE
EF021720TRUE
EF021760TRUE
EF022168TRUE
EF022284FALSE
EF023051Mechanical
EF0230610.0 Pa
EF023686not applicable
EF023957TRUE
EF024792FALSE
EF024885TRUE
EF024921FALSE
EF025090FALSE
EF025091FALSE
EF0250920
EF025093not applicable
EF0250941750
EF025095not applicable
EF025096TRUE
EF0250970.0 L/s
EFSE0002TRUE
Expected Life0
Featuresn/a
Finishn/a
Full Recyclability Of PlasticAll plastic components are fully recyclable
Graden/a
GROHE Social Committmentgreen.grohe.com/social_engagement
GROHE Sustainabilitygreen.grohe.com
HW ConnectionYes
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
KeynoteN13
ManufacturerGrohe
Manufacturer NameGrohe
Materialn/a
ModelRAINSHOWER Shower Set
Model Number22119KF0
Model ReferenceRAINSHOWER Shower Set
NBS DescriptionShower fittings package
NBS Noten/a
NBS Object NameGrohe - Shower fittings package
NBS Office Master Tagn/a
NBS Reference45-35-70/330
Nominal Depth0.0 mm
Nominal Height0.0 mm
Nominal Length0.0 mm
PQ Diagram Linkcdn.cloud.grohe.com/PQCharts/lores/2/221/original/22119KF0-pqchart-en_GB.svg
Primary MaterialGrohe_MattBlack
Product Descriptionconsisting of: horizontal swivable 450 mm shower arm exposed thermostat with Aquadimmer function allows change between: head shower Rainshower Mono 310 with ball joint, rotation angle ± 15° hand shower Rainshower SmartActive 130 (22 127 KF0) adjustable in height with gliding element including performance grip Silverflex shower hose 1750 mm (28 388) GROHE TurboStat compact cartridge with wax thermoelement GROHE SafeStop safety button at 38°C GROHE SafeStop Plus optional temperature limiter at 43°C included GROHE CoolTouch no risk of scalding GROHE DreamSpray perfect spray pattern GROHE SmartTip showering spray selection via push of a ring GROHE Long-Life Shine finish GROHE Water Saving 9.5 l/min flow limiter GROHE FastFixation upper bracket adjustable SpeedClean anti-limescale system suitable for instantaneous heaters from 18 kW/h minimum flow rate 7 l/min
Production Year2023
Product Number22119KF0
Product Page URLwww.grohe.co.uk/en_gb/-22119KF0.html
Product Short TextRainshower System Shower system with thermostat for wall mounting
Product TypeShower System
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsinfo-uk@grohe.com
Sustainability Awardgreen.grohe.com/awards
Sustainability Reportgreen.grohe.com/reporting
TPI Document Linkcdn.cloud.grohe.com/tpi/100000/100000/100000/100200/100210/100218/100218019/original/100218019.pdf
Type CommentsRAINSHOWER Shower Set
Type NameRAINSHOWER Shower Set
URLwww.grohe.co.uk/
Vent ConnectionNo
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com
Waste ConnectionNo

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
