bimstore - Grohe - ATRIO 3-hole basin mixer M-Size (20661DC0)

187
0
- / 5
Rate this product

BS1192:4

Compliant

BSB

Compliant

Object Data

1 Revision

Last Updated

24/09/2023

Download BIM

Add to collection

Available for:

Product Number - 20661DC0

EAN - 4005176763137

Colour - supersteel

PRODUCT MAIN FEATURES

wall mounted
without concealed body
set for final installation for
29 025 002
valves hot/cold with headparts 1/2" - 90°
GROHE Long-Life finish
GROHE EcoJoy 5.7 l/min laminar mousseur
centre distance 200 mm
projection 180 mm
with cross handles
Two different sets of caps included. One set with "H" and "C" marking, one set without marking.

Product Page - https://www.grohe.co.uk/en_gb/atrio-3-hole-basin-mixer-m-size-20661DC0.html

_AuthorSM 151
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/grohe-20661dc0/document/object-user-guide
Accessibility Performancen/a
Assembly CodeD2010
Asset TypeFixed
BIM Object NameGrohe_BasinMixer_Atrio_20661DC0
Classification NameUniclass2015
Classification ValuePr_40_20_87_78
CO2 Neutral ProductionGROHE is one of the first leading manufacturer within the sanitary industry having a CO2-neutral production.
Code Performancen/a
ColorSupersteel
Constituentsn/a
Cradle To Cradle Certificationn/a
Created Byinfo-uk@grohe.com
Created On2023-05-04T09:00:00
Default Elevation0.0 mm
DescriptionATRIO 3-hole basin mixer M-Size
Dimensions Document Linkcdn.cloud.grohe.com/dimdraw/100000/100000/100000/100000/100010/100015/100015067/1280/100015067.jpg
Documentation Certificateswww.bimstore.co/products/grohe-20661dc0/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/grohe-20661dc0/document/installation-guide
Documentation Literaturewww.bimstore.co/products/grohe-20661dc0/document/product-literature
Documentation Maintenancewww.bimstore.co/products/grohe-20661dc0/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/grohe-20661dc0/document/technical-data-sheet
Duration UnitYears
EcojoyNo
EF000010Finishing section
EF00170770 °C
EF002149FALSE
EF002286not applicable
EF002671Stainless steel.
EF0054640
EF011775AA, free air gap
EF011779FALSE
EF0127535.0
EF014578false
EF014591false
EF016731Group I,<= 20 dB(A)
EF020105No
EF020774false
EF020775false
EF020776false
EF020777true
EF020778false
EF020779false
EF020780Two-grip
EF020781Top section, ceramic
EF020782Brass
EF020783Other
EF020784Other
EF020785not applicable
EF0207861
EF020787Group II, <=30 dB(A)
EF020788true
EF020789180.0 mm
EF020790true
EF020963false
EF021855false
EF022042None
EF023686not applicable
EF023687FALSE
EF023957FALSE
EFDE0022Group I, <=20 dB(A)
EFSE0002false
Expected Life0
Featuresn/a
Finishn/a
Full Recyclability Of PlasticAll plastic components are fully recyclable
Graden/a
GROHE Social Committmentgreen.grohe.com/social_engagement
GROHE Sustainabilitygreen.grohe.com
HWFU4.5
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
KeynoteN13
ManufacturerGrohe
Manufacturer NameGrohe
Materialn/a
ModelATRIO 3-hole basin mixer M-Size
Model Number20661DC0
Model ReferenceATRIO 3-hole basin mixer M-Size
NBS DescriptionMixer taps
NBS Noten/a
NBS Object NameGrohe - Mixer Taps
NBS Office Master Tagn/a
NBS Reference45-35-70/345
Nominal Depth0.0 mm
Nominal Height0.0 mm
Nominal Length0.0 mm
PQ Diagram Linkcdn.cloud.grohe.com/PQCharts/lores/2/206/original/20661DC0-pqchart-en_GB.svg
Primary MaterialGrohe_Supersteel
Product Descriptionwall mounted without concealed body set for final installation for 29 025 002 valves hot/cold with ceramic headparts 1/2" - 90° GROHE Long-Life Shine finish GROHE Water Saving 5.7 l/min laminar mousseur center distance 200 mm projection 180 mm with cross handles Two different sets of caps included. One set with "H" and "C" marking, one set without marking.
Production Year2023
Product Number20661DC0
Product Page URLwww.grohe.co.uk/en_gb/-20661DC0.html
Product Short TextAtrio New 2hdl trimset basin 3-h M
Product TypeTwo Handle Fitting
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsinfo-uk@grohe.com
Sustainability Awardgreen.grohe.com/awards
Sustainability Reportgreen.grohe.com/reporting
TPI Document Linkcdn.cloud.grohe.com/tpi/2000/2100/2190/2198/2198292/original/2198292.pdf
Type CommentsATRIO 3-hole basin mixer M-Size
Type NameATRIO 3-hole basin mixer M-Size
URLwww.grohe.co.uk/
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com
