Evomax 2 - Single

Object metadata

• _AuthorIan Holmes
• _Authorized Bybimstore
• _Bim Spec Guid0
• _BS Bible Version16
• _Created Bywww.bimstore.co
• _Current Revision1
• _Distributed Bywww.bimstore.co
• Access Clearance Bottom300 mm
• Access Clearance Front450 mm
• Access Clearance Left25 mm
• Access Clearance Rear300 mm
• Access Clearance Right25 mm
• Access Clearance Top600 mm
• Accessibility Performancen/a
• Additional Technical Detailsidealcommercialboilers.com/
• Air Inlet Connection Size125 mm
• Air Inlet Diameter0 mm
• Assembly CodeD3020100
• Asset TypeFixed
• BIM Object NameIdealBoilers_MechanicalEquiptment_Evomax2
• BMS LinksNo
• Body MaterialIdeal_Heating-Residential-White
• Boiler Output_Maximum 50/30 Degree Celsius101.7
• Boiler Output_Maximum 80/60 Degrees Celsius100
• Building Regulations Seasonal Efficiency96.7
• Burner Control Typen/a
• CE ApprovalYes
• Classification NameUniclass2015
• Classification ValuePr_60_60_08_34
• Clearance MaterialClearance Zone
• Code Performancen/a
• ColorWhite
• ColourWhite
• Condensate Drain Size25 mm
• Condensate Drain Typen/a
• ConfigurationSingle Boiler
• Constituentsn/a
• Control Typen/a
• Created Byidealcommercialboilers.com/contact-us
• Created On2019-08-01T09:00:00
• DescriptionEvomax 2 - LPG
• Documentation Certificatesidealcommercialboilers.com/
• Documentation Installation Guideidealcommercialboilers.com/
• Documentation Literatureidealcommercialboilers.com/
• Documentation Maintenanceidealcommercialboilers.com/
• Documentation Technicalidealcommercialboilers.com/
• Drain Connection Size0 mm
• Drain Connection Typen/a
• Duration UnitYears
• ErP Energy Labeln/a
• ErP Rated Efficiency At Full Load98.2
• ErP Rated Efficiency At Part Load109.4
• ErP Seasonal Efficiencyn/a
• European NOx Class6
• Expected Life0
• External MaterialSteel
• Featuresn/a
• Finishn/a
• Flow And Return Connection Size32 mm
• Flow And Return Connection TypeThreaded
• Flue Connection Size100 mm
• Flue Offset226 mm
• Flue Or Air Intake ClassificationB23, C13, C33, C53
• FrameStainless Steel
• Frame Width550 mm
• Frequency50.00 Hz
• Front Panel MaterialIdeal_Heating-Residential-White
• Fuel Connection Size19 mm
• Fuel Connection TypeThreaded
• Full Load Currentn/a
• Fume Duct Diameter0 mm
• Fuse Rating4A
• Gas Consumption Rate4.35
• Gas Supply0 mm
• Graden/a
• Gross Weight73.00 kg
• Heater Operationn/a
• Heat Exchanger MaterialAluminium
• Heat Exchanger Warranty2
• Hydraulic Resistanceat 11 C Temperature Differentialn/a
• Hydraulic Resistanceat 20 C Temperature Differential134mbar
• Ifc Export AsIfcBoilerType
• Ifc Export TypePset_BoilerTypeCommon
• IK Ratingn/a
• InterlocksNo
• IP RatingIPX4D
• KeynoteT32
• k W100
• Low Loss Header MaterialStainless Steel
• LPGYes
• ManufacturerIdeal Boilers
• Manufacturer NameIdeal Boilers
• Materialn/a
• Maximum Flow Temperature85
• Maximum Gas Inlet Pressuren/a
• Maximum Oil Inlet Pressuren/a
• Maximum Operating Pressure6 bar
• Maximum Power Consumption187 W
• Minimum Flow Rate At 11 C Temperature Differentialn/a
• Minimum Flow Rate At 20 C Temperature Differential71.7 l/min
• Minimum Gas Inlet Pressuren/a
• Minimum Oil Inlet Pressuren/a
• Minimum Operating Pressure0.3 bar
• Minimum Power Consumptionn/a
• ModelEvomax 2 - LPG
• Model Number220827
• Model ReferenceEvomax 2 - LPG
• MountingWall Hung
• NBS DescriptionGas fired condensing boilers
• NBS Object NameIdeal Boilers - Gas fired condensing boilers
• NBS Reference90-40-05/340
• Nominal Depth520 mm
• Nominal Gas Inlet Pressuren/a
• Nominal Height850 mm
• Nominal Length500 mm
• Nominal Oil Inlet Pressuren/a
• NOx Emissions65.3
• Oil Consumption Raten/a
• Optional Fueln/a
• Overall Height850 mm
• Overall Width520 mm
• Pipe Handle ColourIdealBoilers_Plastic_Red
• Pipe Outlet MaterialsStainless Steel
• Primary FuelLPG
• Production Year2019
• Product Literatureidealcommercialboilers.com/
• Product RangeEvomax 2 - LPG
• Rated Criterian/a
• Rated Output100 kW
• Referenced Standardn/a
• Replacement Costn/a
• Safety Valve Connection Size0 mm
• Safety Valve Connection Typen/a
• ShapeCuboid
• Shipping Weight73.00 kg
• Size850(h) x 500(w) x 520(d)mm
• Sound Pressure Level62
• Spare Partsn/a
• Starting Currentn/a
• Supply Phasen/a
• Turndown Ratio5:1
• Type100 kW
• Type CommentsEvomax 2 - 100 kW
• Type NameEvomax 2 - 100 kW
• URLidealcommercialboilers.com/
• Voltage230V
• Warranty DescriptionParts and Labour
• Warranty Duration Labor2
• Warranty Duration Parts2
• Warranty Duration UnitYears
• Warranty Guarantor Labortechnical.help@idealboilers.com
• Warranty Guarantor Partstechnical.help@idealboilers.com
• Water Content7
• Water Treatment Requiredn/a
