Electric Skylight - RWE

by Keylite Roof Windows

Download Add to collection

Description

See the sky and gain fingertip control of natural daylight and ventilation with an electric powered skylight.

The solar control glazing provides 80% heat block for comfort and protection against UV fading in your home.

Object Data

1 Revision

Last Updated

09/05/2025

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Data Sheet

Object metadata

_AuthorBS
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Byinfo@keyliteuk.com
_Object User Guidewww.bimstore.co/products/9793f98f-9fe9-4bd1-b2b6-ac132dc0e56b/document/object-user-guide
2D Detailwww.keyliteroofwindows.com/architects/cad-drawings/
Accessibility Performancen/a
Acoustic Performance32
Air PermeabilityClass 3
Analytic Construction<None>
Angled Opening Bottom40.00 °
Angled Opening Top50.00 °
Assembly CodeB3020100
Asset TypeFixed
BIM Object NameKeylite_Window_ElectricSkylight_RWE
Classification NameUniclass2015
Classification ValuePr_30_59_98_97
Code Performancen/a
Colorn/a
Constituentsn/a
Created Byinfo@keyliteuk.com
Created On2025-05-01T09:00:00
Default Elevation0 mm
Define Thermal Properties bySchematic Type
DescriptionManual Skylight
Documentation Certificateswww.bimstore.co/products/9793f98f-9fe9-4bd1-b2b6-ac132dc0e56b/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/9793f98f-9fe9-4bd1-b2b6-ac132dc0e56b/document/installation-guide
Documentation Literaturewww.bimstore.co/products/9793f98f-9fe9-4bd1-b2b6-ac132dc0e56b/document/product-literature
Documentation Maintenancewww.bimstore.co/products/9793f98f-9fe9-4bd1-b2b6-ac132dc0e56b/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/9793f98f-9fe9-4bd1-b2b6-ac132dc0e56b/document/technical-data-sheet
Duration UnitYears
Expected Life0
Featuresn/a
Finishn/a
Graden/a
Height780 mm
Ifc Export AsIfcWindow
Ifc Export TypeIfcWindowTypeEnum.WINDOW
Impact ResistanceClass 2
Keylite AccessoriesPolistyren
Keylite Construction WoodSosna
Keylite External PartsAluminium
Keylite Internal PartsSosna
Keylite ProfilePolistyren
Keylite Thermal CollarPianka poliuretanowa
KeynoteL10
Level Construction65 mm
Light Transmittance0.85
ManufacturerKeylite
Manufacturer NameKeylite
Materialn/a
ModelRWM
Model NumberRWM
Model ReferenceElectric Skylight - RWE
NBS DescriptionWood frame roof window units
NBS Noten/a
NBS Object NameKeylite - Wood frame roof window units
NBS Office Master Tagn/a
NBS Reference45-25-99/390
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Picture Typekeyliteskylights.com.au/products/skylights/manual-skylight/
Production Year2025
Referenced Standardn/a
Replacement Costn/a
Resistance To Snow Load4H-20, Ar-4TM
Resistance To Wind LoadClass C4
Shapen/a
Sizen/a
Slope40.00 °
Solar Factor G0.65
Spare Partsinfo@keyliteuk.com
Thermal Transmittance Glass1.1
Thermal Transmittance Window1.3
Type CommentsElectric Skylight - RWE - 01
Type NameElectric Skylight - RWE - 01
URLwww.keyliteroofwindows.com
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborinfo@keyliteuk.com
Warranty Guarantor Partsinfo@keyliteuk.com
Warranty Year10
Water TightnessE1050
Width550 mm
