Cubio Heavy Duty Cupboards

Description

This download includes the following products: Cubio - 40013053 - SMF-10520-1.2, 40020110 - SMF-868-1.1, 40021101 - SMF-10620-1.2 & 40021160 - SMF-10620-1.36

Heavy duty cupboards with lockable doors
Housings can support up to 1000kg U.D.L. capacity
Lockable steel doors with perfo liner panels
Galvanised steel shelves, 160kg U.D.L. capacity on 1300mm wide models, 100kg on 800mm / 1050mm
75kg U.D.L. capacity drawers
Full range of division and backpanel accessories
Built to last with 10 year extended guarantee

Object Data

1 Revision

Last Updated

06/04/2021

Available Software

EPD

Not Available

Accompanying literature

Product Literature

Product Data Sheet

Object metadata

_AuthorIH
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/cubio-heavy-duty-cupboards/document/object-user-guide
Accessibility Performancen/a
Assembly CodeE2020
Asset TypeMovable
BIM Object Namebott_Casework_Cupboard_Cubio_(SMF-10520-1.2)
Carcase Back Thickness10 mm
Carcase Shelf Thickness25 mm
Carcase Sides Thickness20 mm
Carcase Top And Bottom Thickness48 mm
Classification NameUniclass2015
Classification ValuePr_40_30_78_27
Code Performancen/a
ColorBlue
Constituentsn/a
Construction TypeSheet Steel
Created Byinfo@bottltd.co.uk
Created On2021-03-17T09:00:00
Depth525 mm
DescriptionCubio SMF-10520-1.2 cupboard with lockable doors with perforated inner panels. Complete with 4 shelves, each with 100kg load capacity adjustable on 25mm pitch
Documentation Certificateswww.bimstore.co/products/cubio-heavy-duty-cupboards/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/cubio-heavy-duty-cupboards/document/product-certificates
Documentation Literaturewww.bimstore.co/products/cubio-heavy-duty-cupboards/document/product-literature
Documentation Maintenancewww.bimstore.co/products/cubio-heavy-duty-cupboards/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/cubio-heavy-duty-cupboards/document/technical-data-sheet
Door Gap4 mm
Door Thickness20 mm
Duration UnitYears
Expected Life0
Featuresn/a
FinishPowder Coated
Graden/a
Height2000 mm
Ifc Export AsIfcFurniture
Ifc Export TypeIfcFurnitureTypeEnum.SHELF
KeynoteE
ManufacturerBott Ltd
Manufacturer NameBott Ltd
MaterialSteel
Material Primarybott, Metal, Powder Coated, RAL7035, Light Grey
Material Secondarybott, Metal, Powder Coated, RAL5010, Blue
Modelcubio Cupboard
Model Number40013053.11V
Model Referencecubio Cupboard
NBS DescriptionEquipment storage racks
NBS Object Namebott - Equipment storage racks
NBS Office Master Tagn/a
NBS Referencen/a
Nominal Depth525 mm
Nominal Height2000 mm
Nominal Length1050 mm
Plinth Height0 mm
Production Year2021
Referenced Standardn/a
Replacement Costn/a
ShapeRectangular
Size1050(W)mm x 525(D)mm x 2000(H)mm
Spare Partsn/a
Type Comments40013053.11V
Type Name1050(W)mm x 525(D)mm x 2000(H)mm - Blue
URLwww.bottltd.co.uk/workplace-storage/product-catalogue/40013053-cubio-cupboard.html
Warranty DescriptionAll Bott manufactured workplace storage products benefit from a 10 year guarantee.
Warranty Duration Labor0
Warranty Duration Parts10
Warranty Duration UnitYears
Warranty Guarantor Laborn/a
Warranty Guarantor Partsinfo@bottltd.co.uk
Width1050 mm
