Channel 673 - SAG 11693

Download Add to collection

Description

Caniveau type 673 à fente largeur 8 mm, tout inox nuance 304 (1.4301 selon NF EN 10088-1).

Fente désaxée en alignement sur une face du corps de caniveau, avec en partie haute finition à plis pincés et entretoises de renfort.
Equerres pour fixation mécanique à chaque extrémité, pattes à scellement réparties sur la longueur.
Pentes intégrées vers évacuation coudée / verticale DN 75 en extrémité.

Object Data

1 Revision

Last Updated

02/11/2020

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Product Data Sheet

Object metadata

_AuthorIan Holmes
_Bim Spec Guid0
_BS Bible Version15
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
a78.86 °
Accessibility Performancen/a
Assembly CodeD2030300
Asset TypeFixed
BIM Object NameBlucher_PlumbingFixture_Channel_673_SAG11693
Channel Product CodeSAG 11693
Classification NameUniclass2015
Classification ValuePr_65_52_24_47
Code Performancen/a
ColorStainless Steel
Constituentsn/a
Created Bymail@blucher.com
Created On2019-10-10T09:00:00
CW ConnectionNo
Default Elevation0 mm
DescriptionKitchen Channel 673 - Floor: concrete, tiled and resin
Dia75 mm
Documentation Certificateswww.bimstore.co/products/channel-673-sag-11693/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/channel-673-sag-11693/document/installation-guide
Documentation Installation Videowww.blucher.com/com/technical/installation-video-channels-and-kitchen-channels/
Documentation Literaturewww.bimstore.co/products/channel-673-sag-11693/document/product-literature
Documentation Maintenancewww.bimstore.co/products/channel-673-sag-11693/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/channel-673-sag-11693/document/technical-data-sheet
Duration UnitYears
Expected Life50
F1200 mm
F175 mm
Featuresn/a
Finish2B - Pickled
GradeAISI 304/EN 1.4301 or AISI 316L/EN 1.4404
H363 mm
H198 mm
H5265 mm
Height From Level0 mm
HW ConnectionNo
Ifc Export AsIfcFlowTerminal
Ifc Export TypeIfcWasteTerminalTypeEnum.FLOORWASTE
KeynoteR10
LH EndYes
ManufacturerBLÜCHER
Manufacturer NameBLÜCHER
MaterialAvailable in Stainless Steel AISI 304 & Stainless Steel AISI 316L
ModelBLÜCHER SAG 11693
Model ReferenceBLÜCHER SAG 11693
NBS DescriptionLinear slot drainage channels
NBS Object NameBLÜCHER - Linear slot drainage channels
NBS Office Master Tagn/a
NBS Reference90-05-20/426
Nominal Depth75 mm
Nominal Height363 mm
Nominal Length1200 mm
Production Year2019
Referenced StandardEN1253
Replacement Costn/a
RH EndNo
ShapeRectangular
Size1200(L) x 363(H) x 75(W)
Spare Partsn/a
T2 mm
Type CommentsSlot Channel SAG 11693
Type NameSlot Channel SAG 11693
URLwww.blucher.com/
Vent ConnectionNo
W3100 mm
Warranty Descriptionn/a
Warranty Duration Laborn/a
Warranty Duration Partsn/a
Warranty Duration UnitYears
Warranty Guarantor Laborn/a
Warranty Guarantor Partsmail@blucher.com
Waste ConnectionYes

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
